Omron S8VS User Manual

S8VS
3
*4) The overvoltage protection of the S8VS-01524 uses a zener diode clamp. If the internal feedback circuit is destroyed by any chance, the load may be destroyed by the
clamped output voltage (approx. 140% to 190% of the rated output voltage).
*5) To reset the protection, turn OFF the input power for three minutes or longer and then turn it back ON.
*6) To ensure the emission rating, a ferrite ring core should be used in all cabling (SEIWA E04SR301334 or equivalent model).
*7) MTBF stands for mean Time Between Failures, which is calculated according to the probability of accidental device failures,
and indicates reliability of devices.
Item Power ratings 120 W 240 W 480 W
Efficiency (typical) 80% min. 83% min.
Input
Voltage *1 100 to 240 VAC (85 to 264 VAC)
Frequency *1 50/60 Hz (47 to 63 Hz)
Current
100 V input 1.9 A max. 3.8 A max. 7.4 A max.
200 V input 1.1 A max. 2.0 A max. 3.9 A max.
Power factor 0.95 min.
Harmonic current emissions Conforms to EN61000-3-2
Leakage current
100 V input 0.5 mA max.
200 V input 1.0 mA max.
Inrush current *2
100 V input 25 A max. (for a cold start at 25°C)
200 V input 50 A max. (for a cold start at 25°C)
Output
Voltage adjustment range *3 −10% to 15% (with V.ADJ) (guaranteed)
Ripple 2.0% (p-p) max. (at rated input/output voltage)
Input variation influence 0.5% max. (at 85 to 264 VAC input, 100% load)
Load variation influence
(rated input voltage)
1.5% max. (with rated input, 0 to 100% load)
Temperature variation influence 0.05%/°C max.
Startup time *2 1,000 ms max. (at rated input/output voltage)
Hold time *2 20 ms min. (at rated input/output voltage)
Additional
functions
Overload protection *2
105% to 160% of rated load current,
voltage drop, intermittent, automatic
reset
105% to 160% of rated load current, voltage drop, automatic reset
Overvoltage protection *2 Yes
Parallel operation No
Series operation Yes for up to 2 Power Supplies (with external diode)
Other
Operating ambient temperature Refer to the derating curve in Engineering Data . (with no icing or condensation)
Storage temperature −25 to 65°C
Operating ambient humidity 25% to 85% (Storage humidity: 25% to 90%)
Dielectric strength
3.0 kVAC for 1 min. (between all inputs and outputs/ alarm outputs; detection current: 20 mA)
2.0 kVAC for 1 min. (between all inputs and PE terminals; detection current: 20 mA)
1.0 kVAC for 1 min. (between all outputs/ alarm outputs and PE terminals; detection current: 240 W, 20 mA/ 480 W,
30 mA)
500 VAC for 1 min. (between all outputs and alarm outputs; detection current: 20 mA)
Insulation resistance 100 MΩ min. (between all outputs/ alarm outputs and all inputs/ PE terminals) at 500 VDC
Vibration resistance
10 to 55 Hz, 0.375-mm single amplitude for 2 h each in X, Y, and Z directions
10 to 150 Hz, 0.35-mm single amplitude (5 G max.) for 80 min each in X, Y, and Z directions (only for 240 W)
10 to 150 Hz, 0.35-mm single amplitude (3 G max.) for 80 min each in X, Y, and Z directions (only for 480 W)
Shock resistance
150 m/s
2
, 3 times each in ±X, ±Y, and ±Z directions
Output indicator Yes (color: green)
EMI
Conducted
Emissions
Conforms to EN61204-3 EN55011 Group 1 Class B and based
on FCC Class A
Conforms to EN61204-3 EN55011
Class A and based on FCC Class A
Conforms to EN61204-3 EN55011
Class B *6
Radiated
Emissions
Conforms to EN61204-3 EN55011 Group 1 Class B
Conforms to EN61204-3 EN55011
Class A
Conforms to EN61204-3 EN55011
Class B *6
EMS Conforms to EN61204-3 high severity levels
Approved standards
UL: UL508 (Listing), UL60950-1
cUL: CSA C22.2 No. 107.1
UL: UL508 (Listing), UL60950-1
cUR: CSA No. 60950-1
EN/VDE: EN50178 (= VDE0160), EN60950-1 (SELV) (= VDE0805 Teil 1)
According to VDE0106/P100, IP20 (except terminal block)
UL: UL508 (Listing), UL60950-1
cUL: CSA C22.2 No. 107.1
UL: UL508 (Listing), UL60950-1
cUR: CSA No. 60950-1
EN/VDE: EN50178 (= VDE0160),
EN60950-1 (SELV) (= VDE0805 Teil 1)
According to VDE0106/P100, IP20
(except terminal block)
SEMI F47-0200 (200 VAC input)
MTBF*7 >250.000 hrs
Weight 550 g max. 1,150 g max. 1,700 g max.
T01E-EN-02+S8VS+Datasheet.fm Seite 3 Dienstag, 4. November 2008 6:58 18

Omron S8VS Specifications

General

Input Voltage	100 to 240 VAC, 50/60 Hz
Output Power	60 W, 120 W (depending on model)
Mounting	DIN rail mounting
Safety Standards	UL508, CSA C22.2 No. 107.1, EN50178, IEC/EN60950-1
Protection Features	Overcurrent protection, Overvoltage protection, Short-circuit protection
Output Voltage	24 VDC
