S8VS
10
Mounting Brackets
Note: Brackets cannot be used for 480 W models.
Type Model Dimensions Appearance
Side-mounting Bracket
(For 15, 30 W models)
S82Y-VS30P
Side-mounting Bracket
(For 60, 120 W models)
S82Y-VS10S
Side-mounting Bracket
(For 240 W models)
S82Y-VS20S
Front-mounting Bracket
(For 60, 120, and 240 W
models) *1
*1) Two required to mount a 240 W model.
S82Y-VS10F
7.1
3.5
0.5
15
15
93.6
109.4
±0.1
85.4
22.5
34
28
t = 0.8
15
3.5 dia.
35
64
t = 2.0
80
60
±0.1
55
±0.1
13
4.5 dia.
±0.1
Left-side mounting Right-side mounting
60
±0.1
55
±0.1
13
80
78
114
4.5 dia.
±0.1
t = 2.0
60
Left-side mounting
*Right-side mounting also possible.
41
35
±0.1
40
50
4.5 dia.±0.1
35
25
10
7.3
(For 60 W,
120 W types)
(For 240 W type)
*Use two S82Y-VS10F
brackets for the 240 W type.
T01E-EN-02+S8VS+Datasheet.fm Seite 10 Dienstag, 4. November 2008 6:58 18
