Dimensions
Note: All units are in millimeters unless otherwise indicated.
Note: The illustration is the S8VS-03024 model.
4.8
(Sliding: 10 max.)
4.8
(Sliding: 10 max.)
35.2
96.4
22.5
4
85
Rail stopper
S8VS-01524 (15 W)
S8VS-03024 (30 W)
97
11.3
35.4
108.3
1
40
10
74
95
Five, M4
with square washer
Rail stopper
4.5
(Sliding: 15 max.)
S8VS-06024 (60 W)
110.5
10.8
34.9
121.3
1
94
115
10
50
Five, M4
with square washer
Rail stopper
Screwless block (2.5-mm pitches)
4.5
(Sliding: 15 max.)
S8VS-12024 (120 W)
125.3
120.3
34.9
10
50
94
100
115
Seven, M4
with square washer
Rail stopper
4.5 (Sliding: 15 max.)
Rail stopper
Screwless block (2.5-mm pitches)
S8VS-24024 (240 W)
S8VS-48024 (480 W)
10
70
Rail stopper
Nine, M4 with square washer
4.5 (Sliding: 15 max.)
Rail stopper
123.8
127.2
34.9
94
115
115
150
Screwless block (2.5-mm pitches)
