S8VS
2
Specifications
Ratings/Characteristics
*1) Do not use an inverter output for the Power Supply. Inverters with an output frequency of 50/60 Hz are available, but the rise in the internal temperature of the Power
Supply may result in ignition or burning.
*2) Refer to
Engineering Data
on page 7 for details.
*3) If the output voltage adjuster (V. ADJ) is turned, the voltage will increase by more than +15% of the voltage adjustment range. When adjusting the output voltage, confirm
the actual output voltage from the Power Supply and be sure that the load is not damaged.
Item Power ratings 15 W 30 W 60 W
Efficiency (typical) 77% min. 80% min. 78% min.
Input
Voltage*1 100 to 240 VAC (85 to 264 VAC)
Frequency *1 50/60 Hz (47 to 450 Hz)
Current
100 V input 0.45 A max. 0.9 A max. 1.7 A max.
200 V input 0.25 A max. 0.6 A max. 1.0 A max.
Power factor ---
Harmonic current emissions Conforms to EN61000-3-2
Leakage
current
100 V input 0.5 mA max.
200 V input 1.0 mA max.
Inrush
current *2
100 V input 25 A max. (for a cold start at 25°C)
200 V input 50 A max. (for a cold start at 25°C)
Output
Voltage adjustment range *3 −10% to 15% (with V.ADJ)
Ripple 2.0% (p-p) max. (at rated input/output voltage)
Input variation influence 0.5% max. (at 85 to 264 VAC input, 100% load)
Load variation influence
(rated input voltage)
2.0% max. (5 V), 1.5% max. (12 V, 24 V),
(with rated input, 0 to 100% load)
1.5% max. (with rated input, 0 to
100% load)
Temperature variation influence 0.05%/°C max.
Startup time *2
100 ms max.
(at rated input/output voltage)
1,000 ms max. (at rated input/output voltage)
Hold time *2 20 ms min. (at rated input/output voltage)
Additional
functions
Overload protection *2
105% to 160% of rated load current,
voltage drop, automatic reset
105% to 160% of rated load current, voltage drop, intermittent operation,
automatic reset
Overvoltage protection *2 Yes (a zener diode clamp) *4 Yes *5 Yes
Undervoltage alarm indication Yes (color: red) No
Parallel operation No
Series operation Yes for up to 2 Power Supplies (with external diode)
Other
Operating ambient temperature Refer to the derating curve in
Engineering Data
. (with no icing or condensation)
Storage temperature −25 to 65°C
Operating ambient humidity 25% to 85% (Storage humidity: 25% to 90%)
Dielectric strength
3.0 kVAC for 1 min. (between all inputs and outputs; detection current: 20 mA)
2.0 kVAC for 1 min. (between all inputs and PE terminals; detection current: 20 mA)
1.0 kVAC for 1 min. (between all outputs and PE terminals; detection current: 20 mA)
500 VAC for 1 min. (between all outputs and alarm outputs; detection current: 20 mA) (only for 60 W)
Insulation resistance 100 MΩ min. (between all outputs and all inputs/ PE terminals) at 500 VDC
Vibration resistance
10 to 55 Hz, 0.375-mm single amplitude for 2 h each in X, Y, and Z directions
10 to 150 Hz, 0.35-mm single amplitude (5 G max.) for 80 min each in X, Y, and Z directions (only for 60 W)
Shock resistance
150 m/s
2
, 3 times each in ±X, ±Y, and ±Z directions
Output indicator Yes (color: green)
EMI
Conducted
Emissions
Conforms to EN61204-3 EN55011 Class B and based on FCC Class A
Conforms to EN61204-3 EN55011
Group 1 Class B and based on FCC Class A
Radiated
Emissions
Conforms to EN61204-3 EN55011 Class B
Conforms to EN61204-3 EN55011
Group 1 Class B
EMS Conforms to EN61204-3 high severity levels
Approved standards
UL: UL508 (Listing; Class 2: Per UL1310), UL60950-1, UL1604 (Class I/Division2)
cUL: CSA C22.2 No.14 (Class 2), No.60950-1, No.213 (Class I/Division2)
cUL: CSA C22.2 No.14 (Class 2), No.60950-1, No.213 (Class I/Division2)
EN/VDE: EN50178 (=VDE0160), EN60950-1 (SELV) (=VDE0805 Teil 1)
According to VDE0106/P100, IP20 (except terminal block)
UL for standard models: UL508 (Listing;
Class 2:Per UL1310), UL60950-1
cUL: CSA C22.2 No.107.1(Class 2:
Per CSA C22.2 No. 223)
cUR: CSA No.60950-1
EN/VDE: EN50178 (= VDE0160),
EN60950-1
(SELV) (= VDE0805 Teil 1)
According to VDE 0106/P100, IP20
(except terminal block)
SEMI F47-0200 (200 VAC input)
MTBF *7 > 500.000 hrs > 250.000 hrs
Weight 160 g max. 180 g max. 330 g max.
T01E-EN-02+S8VS+Datasheet.fm Seite 2 Dienstag, 4. November 2008 6:58 18
