3-43
3-4 Cable and Connector Specifications
3
Specifications
Connector Specifications
 Main Circuit Connector (R7A-CNB01P)
The Main Circuit Connector connects to the Servo Drive’s Main Circuit Connector (CNA).
Dimensions
11.6
10.7
19.6
3.5
8.56.3
16.8
22.2
2.7 2.7
4.2
4.2
9.6
3
5.4
Connector pins:
5556PBTL (Molex Japan)
Connector case:
5557-10R-210 (Molex Japan)
