3-54
3-4 Cable and Connector Specifications
3
Specifications
Terminal Block Signal Names
No. Signal
1+24VIN
2RUN
3 RESET
4 ECRST/VSEL2
5 GSEL/VZERO/TLSEL
6 SESEL/VSEL1
7NOT
8POT
9/ALM
10 INP/TGON
11 BKIR
12 WARN
13 OGND
14 GND
15 +A
16 −A
17 −B
18 +B
19 +Z
20 −Z
21 Z
22 +CW/+PULS/+FA
23 −CW/−PULS/−FA
24 +CCW/+SIGN/+FB
25 −CCW/−SIGN/−FB
26 FG
27
28
29
30
31
32
33
34
