4-9
4-1 Installation Conditions
4
System Design
Installing Decelerator into the Machine
When you install the R88G-VRXF@@@ into the machine, confirm that the mounting surface is flat
and there are no burrs on the tap sections, and fix the mounting flange with bolts.
Mounting Flange Bolt Tightening Torque for Aluminum
Note If the key on a Servomotor with key is uninstalled, it is possible to use the Decelerator by
installing the Servomotor without above mentioned key.
Slipping does not occur.
Decelerator model
R88G-VRXF
Number of
bolts
Bolt size
Mounting PCD
(mm)
Tightening
torque (N·m)
B frame 4 M5 60 5.8
C frame 4 M6 90 9.8
