2-1 Standard Models
2
Standard Models and Dimensions
 Backlash = 15’ Max.
For 3,000-r/min Cylindrical Servomotors
Note 1. The standard models have a straight shaft with a key.
Note 2. The backlash is the value when a load of ±4% of the allowable output torque is applied to
the output shaft.
Note 3. For new use of a 15 Arcminutes Max. model, we recommend the successor model VRXF
Series.
Specifications
Model
Motor capacity Gear ratio
50 W
1/5 R88G-VRXF05B100CJ
1/9 R88G-VRXF09B100CJ
1/15 R88G-VRXF15B100CJ
1/25 R88G-VRXF25B100CJ
100 W
1/5 R88G-VRXF05B100CJ
1/9 R88G-VRXF09B100CJ
1/15 R88G-VRXF15B100CJ
1/25 R88G-VRXF25B100CJ
200 W
1/5 R88G-VRXF05B200CJ
1/9 R88G-VRXF09C200CJ
1/15 R88G-VRXF15C200CJ
1/25 R88G-VRXF25C200CJ
400 W
1/5 R88G-VRXF05C400CJ
1/9 R88G-VRXF09C400CJ
1/15 R88G-VRXF15C400CJ
1/25 R88G-VRXF25C400CJ
