18 AC servo systems
Cable for CN3
Filters
Connectors
External regeneration resistor
External regeneration resistor cable
Parameter unit & computer software
K
Position control unit connecting cable CJ1W-NC133 0.5 m XW2Z-050J-A18
1 m XW2Z-100J-A18
CJ1W-NC233/433 0.5 m XW2Z-050J-A19
1 m XW2Z-100J-A19
CS1W-NC133 0.5 m XW2Z-050J-A10
1 m XW2Z-100J-A10
CS1W-NC233/433 0.5 m XW2Z-050J-A11
1 m XW2Z-100J-A11
CJ1W-NC113 0.5 m XW2Z-050J-A14
1 m XW2Z-100J-A14
CJ1W-NC213/413 0.5 m XW2Z-050J-A15
1 m XW2Z-100J-A15
CS1W-NC113
C200HW-NC113
0.5 m XW2Z-050J-A6
1 m XW2Z-100J-A6
CS1W-NC213/413
C200HW-NC213/413
0.5 m XW2Z-050J-A7
1 m XW2Z-100J-A7
CJ1M-CPU21/22/23 0.5 m XW2Z-050J-A33
1 m XW2Z-100J-A33
CQM1H-PLB21
CQM1-CPU43-V1
0.5 m XW2Z-050J-A3
1 m XW2Z-100J-A3
L
General purpose cable For general purpose controllers 1 m R7A-CPB001S
2 m R7A-CPB002S
M
Terminal block cable For general purpose controllers 1 m XW2Z-100J-B28
2 m XW2Z-200J-B28
N
Terminal block ( with M3 screw and for pin terminals) - XW2B-34G4
Terminal block ( with M3.5 screw and for fork/round terminals) - XW2B-34G5
Terminal block ( with M3 screw and fork/round pin terminals) - XW2D-34G6
Symbol Name Lengh Model
O
Personal Computer Monitor Cable 2 m R88A-CCG002P2
Symbol Applicable servo drive Rated current Rated voltage Filter model
P
R7D-BP01H/ 02HH/ 04H 4 A 1 pH, 230 V R7A-FIB104-RE
Specifications Model
Main Circuit Connector (CNA) R7A-CNB01P
Servomotor Connector (CNB) R7A-CNB01A
Control I/O Connector (CN1) R88A-CNW01C
Encoder Input Connector (CN2) R88A-CNW01R
Servomotor Connector for Encoder Cable R88A-CNG02R
Servomotor Connector for Servomotor Power Cable R88A-CNG01A
Brake Cable Connector R88A-CNG01B
Specification Model
80 W, 50 Ω R88A-RR08050S
80 W, 100 Ω R88A-RR080100S
220 W, 47 Ω R88A-RR22047S
Specifications Model
External Regenerative Resistor Connection Cable, 2 meters R7A-CLB002RG
Specifications Model
Parameter copy unit (with cable) R88A-PR02G
Configuration and monitoring software tool for servo drives and inverters. (CX-drive version 1.8 or higher) CX-drive
Symbol Description Connect to Model
