Page #116 background image
7-12
Constant
no.
SettingSetting rangeDescriptionIndi-
cators
n14 Frequency
reference 4
0.0 to 400 (Hz) [0.0]
n15 Frequency
reference 5
0.0 to 400 (Hz) [0.0]
n16 Frequency
reference 6
0.0 to 400 (Hz) [0.0]
n17 Frequency
reference 7
0.0 to 400 (Hz) [0.0]
n18 Frequency
reference 8
0.0 to 400 (Hz) [0.0]
n19 Inching
frequency
command
0.0 to 400 (Hz) [6.0]
n20 Acceleration
time 1
0.0 to 999 (seconds) [10.0]
n21 Deceleration
time 1
0.0 to 999 (seconds) [10.0]
n22 Acceleration
time 2
0.0 to 999 (seconds) [10.0]
n23 Deceleration
time 2
0.0 to 999 (seconds) [10.0]
n24 Maximum
frequency
50.0 to 400 (Hz) [60.0]
n25 Maximum
voltage
1 to 255 (V) (see note 1) [200]
n26 Maximum
voltage
frequency (basic
frequency)
0.6 to 400 (Hz) [60.0]
n27 Intermediate
output frequency
0.1 to 399 (Hz) [1.5]
n28 Intermediate
output frequency
voltage
1 to 255 (V) (see note 1) [12]
n29 Minimum output
frequency
0.1 to 10.0 (Hz) [1.5]
n30 Minimum output
frequency
voltage
1 to 50 (V) (see note 1) [12]
n31 Electronic
thermal
reference
current
0.0 to 120% of rated Inverter amperage
Specify the rated motor amperage.
Appendix A Chapter 7
