7-11
Constant
no.
SettingSetting rangeDescriptionIndi-
cators
9: External base block command (base
block when ON)
10: External base block command (base
block when OFF)
11: Search command from maximum
frequency
12: Search command from preset
frequency
13: Acceleration/Deceleration-inhibit
command
14: Local/Remote changeover
command
n07 Multi-function
input selection 2
1 to 14: Same as for n06 [2]
Invalid when n08 = 15
n08
Multi-function
1 to 14: Same as for n06 [4]
input selection 3
15: Up/Down command
n09
Multi-function
0: Fault occurrence
output selection
1: Operation in progress
1 (MA, MB)
2: Frequency matching
3: Idling
4: Frequency detection
Output frequency ≥ frequency detection
level determined with constant set in n53
5: Frequency detection
Output frequency ≤ frequency detection
level determined with constant set in n53
6: Over-torque being monitored
7: Base block in progress
8: Undervoltage (UV) being monitored
9: Speed search
10: Run mode
n10 Multi-function
input selection 2
(PA)
0 to 10: Same as for n09 [0]
n11 Frequency
reference 1
0.0 to 400 (Hz) [6.0]
n12 Frequency
reference 2
0.0 to 400 (Hz) [0.0]
n13 Frequency
reference 3
0.0 to 400 (Hz) [0.0]
Appendix A Chapter 7
