7-14
Constant
no.
SettingSetting rangeDescriptionIndi-
cators
n43 Frequency
0: Frequency reference
reference input
terminal
1: Fault reset
n44 Multi-function
0: Output frequency
analog output
1: Output current
n45 Multi-function
analog output
gain
0.00 to 2.00 [0.30]
n46 DC control
current
0 to 100 (%) [50]
n47 Interruption DC
control time
0.0 to 5.0 (seconds) [0.5]
n48 Startup DC
control time
0.0 to 5.0 (seconds) [0.0]
n49 S-shape
acceleration and
0: No s-shape acceleration or
deceleration
deceleration
characteristic
1: S-shape characteristic time set to 0.2
second
2: S-shape characteristic time set to 0.5
second
3: S-shape characteristic time set to 1.0
second
n50 Over-torque
0: Inverter does not monitor over-torque.
detection
function
selection
1: Inverter monitors over-torque only
when speed is matched. It continues
operation even when over-torque is
detected.
2: Inverter monitors over-torque only
when speed is matched. It
discontinues operation when
over-torque is detected.
3: Inverter always monitors over-torque
during operation. It continues
operation even when over-torque is
detected.
4: Inverter always monitors over-torque
during operation. It discontinues
operation when over-torque is
detected.
n51 Over-torque
detection level
30 to 200 (%) [160]
n52 Over-torque
detection time
0.1 to 10.0 (seconds) [0.1]
Appendix A Chapter 7
