4-10
Constant
no.
Factory settingSetting rangeDescriptionDedicated
indicator
n05 Reverse rotation-inhibit
selection
0, 1 0
n06 Multi-function input selec-
tion 1 (S1)
0 to 14 1
n07 Multi-function input selec-
tion 2 (S2)
1 to 14 2
n08 Multi-function input selec-
tion 3 (S3)
1 to 15 4
n09 Multi-function output selec-
tion 1 (MA and MB)
0 to 10 1
n10 Multi-function output selec-
tion 2 (PA)
0 to 10 0
n11 Frequency reference 1 0.0 to 400 6.0 (Hz)
n12 Frequency reference 2 0.0 to 400 0.0 (Hz)
n13 Frequency reference 3 0.0 to 400 0.0 (Hz)
n14 Frequency reference 4 0.0 to 400 0.0 (Hz)
n15 Frequency reference 5 0.0 to 400 0.0 (Hz)
n16 Frequency reference 6 0.0 to 400 0.0 (Hz)
n17 Frequency reference 7 0.0 to 400 0.0 (Hz)
n18 Frequency reference 8 0.0 to 400 0.0 (Hz)
n19 Inching frequency com-
mand
0.0 to 400 6.0 (Hz)
n20 Acceleration time 1 0.0 to 999 10.0 (seconds)
n21 Deceleration time 1 0.0 to 999 10.0 (seconds)
n22 Acceleration time 2 0.0 to 999 10.0 (seconds)
n23 Deceleration time 2 0.0 to 999 10.0 (seconds)
n24 Maximum frequency 50.0 to 400 60.0 (Hz)
n25 Maximum voltage 1 to 255
(see note 1)
200 (V)
(see note 1)
n26 Maximum voltage frequency 0.6 to 400 60.0 (Hz)
n27 Intermediate output fre-
quency
0.1 to 399 1.5 (Hz)
n28 Intermediate output fre-
quency voltage
1 to 255
(see note 1)
12 (V)
(see note 1)
n29 Minimum output frequency 0.1 to 10.0 1.5 (Hz)
Preparing for Operation Chapter 4
