Appendices
A-94
CP2E CPU Unit Software User’s Manual(W614)
A618 08
to
11
Serial Port 2 Built-in
RS-485 Port Commu-
nication Settings
Display the present communication
settings of the serial port 2 or Built-in
RS-485 Port. Reflect the PLC Setup
when power is turned ON.
Communication
speed
0 hex: Default (9600)
3 hex: 1200
4 hex: 2400
5 hex: 4800
6 hex: 9600
7 hex: 19200
8 hex: 38400
9 hex: 57600
A hex: 115200
Retained See
Function
column.
Refreshed
when power is
turned ON.
12
to
15
Communication
mode
0 hex: Default (Host
Link)
2 hex: NT link(1: N)
3 hex: Non-protocol
5 hex: Host Link
7 hex: Serial PLC
Link (Slave)
8 hex: Serial PLC
Link (Master)
9 hex: Modbus-RTU
Easy Master
D hex: Modbus-RTU
Slave
Retained See
Function
column.
Refreshed
when power is
turned ON.
A638 00 Serial Port 1(EX)
Modbus-RTU Easy
Master Execution
Flag (CP2E
N-type CPU Unit
only)
Turn ON this bit to send a command
and receive a response for the serial
port 1(EX) using the Modbus-RTU
easy master function.
Note This bit will be turned OFF auto-
matically by the system when
communications have been com-
pleted.
Turned ON: Execu-
tion started
ON: Execution in
progress.
OFF: Not executed
or execution
completed.
Retained Cleared --- DM Area
words for
serial
port
1(EX)
Mod-
bus-RTU
Easy
Master:
D1400 to
D1499
01 Serial Port 1(EX)
Modbus-RTU Easy
Master Normal End
Flag (CP2E
N-type CPU Unit
only)
ON when one command has been
sent and the response received for the
serial port 1(EX) using the Mod-
bus-RTU easy master function.
ON: Execution nor-
mal.
OFF: Execution error
or still in
progress.
Retained Cleared Written after
reception.
02 Serial Port 1(EX)
Modbus-RTU Easy
Master Error End Flag
(CP2E N-type
CPU Unit only)
ON when an error has occurred in
communications for the serial port
1(EX) using the Modbus-RTU easy
master function.
The error code is output to D1452 in
the DM fixed allocation words for Mod-
bus-RTU Easy Master.
ON: Execution error.
OFF: Execution
normal or still
in progress.
Retained Cleared Written when
error ends.
D1452
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
