CP2E CPU Unit Software User’s Manual(W614)
A-2 Auxiliary Area Allocations by Address
App
A-2-2 Read/Write Words
A617 00 Serial Port 1/
Built-in RS232C Port
Communication Set-
tings
Display the present communication
settings of the serial port 1 or built-in
RS232C port. Reflect the PLC Setup
when power is turned ON.
Parity
0: Even
1: Odd
Retained See
Function
column.
Refreshed
when power is
turned ON.
01 Parity
0: Yes
1: No
Retained See
Function
column.
Refreshed
when power is
turned ON.
02 Stop bit
0: 2 bits
1: 1 bit
Retained See
Function
column.
Refreshed
when power is
turned ON.
03 Data length
0: 7 bits
1: 8 bits
Retained See
Function
column.
Refreshed
when power is
turned ON.
04 Start bit
0: 1 bit (fixed)
Retained See
Function
column.
Refreshed
when power is
turned ON.
08
to
11
Communication
speed
0 hex: Default (9600)
3 hex: 1200
4 hex: 2400
5 hex: 4800
6 hex: 9600
7 hex: 19200
8 hex: 38400
9 hex: 57600
A hex: 115200
Retained See
Function
column.
Refreshed
when power is
turned ON.
12
to
15
Communication
mode
0 hex: Default (Host
Link)
2 hex: NT link (1: N)
3 hex: Non-protocol
5 hex: Host Link
7 hex: Serial PLC
Link (Slave)
8 hex: Serial PLC
Link (Master)
9 hex: Modbus-RTU
Easy Master
D hex: Modbus-RTU
Slave
Retained See
Function
column.
Refreshed
when power is
turned ON.
A618 00 Serial Port 2/
Built-in RS-485 Port
Communication Set-
tings
Display the present communication
settings of the serial port 2 or built-in
RS-485 port. Reflect the PLC Setup
when power is turned ON.
Parity
0: Even
1: Odd
Retained See
Function
column.
Refreshed
when power is
turned ON.
01 Parity
0: Yes
1: No
Retained See
Function
column.
Refreshed
when power is
turned ON.
02 Stop bit
0: 2 bits
1: 1 bit
Retained See
Function
column.
Refreshed
when power is
turned ON.
03 Data length
0: 7 bits
1: 8 bits
Retained See
Function
column.
Refreshed
when power is
turned ON.
04 Start bit
0: 1 bit (fixed)
Retained See
Function
column.
Refreshed
when power is
turned ON.
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
