Appendices
A-92
CP2E CPU Unit Software User’s Manual(W614)
A583 00 I/O Memory Backup
Error Flag
The flag will be ON when the I/O
memory is not held at power ON.
It will still be ON until the memory area
is cleared or the flag is turned OFF
manually.
ON: I/O memory
backup error
occurred
OFF: Normal
Retained Retained Refreshed
when the
power is
turned ON.
A403.14
A616
00
Serial Port 1 (EX)
Communication
Settings
Display the present communication
settings of the serial port 1 (EX).
Reflect the PLC Setup when power is
turned ON.
Parity
0: Even
1: Odd
Retained See
Function
column.
Refreshed
when power is
turned ON.
01 Parity
0: Yes
1: No
Retained See
Function
column.
Refreshed
when power is
turned ON.
02 Stop bit
0: 2 bits
1: 1 bit
Retained See
Function
column.
Refreshed
when power is
turned ON.
03 Data length
0: 7 bits
1: 8 bits
Retained See
Function
column.
Refreshed
when power is
turned ON.
04 Start bit
0: 1 bit (fixed)
Retained See
Function
column.
Refreshed
when power is
turned ON.
08
to
11
Communication
speed
0 hex: Default (9600)
3 hex: 1200
4 hex: 2400
5 hex: 4800
6 hex: 9600
7 hex: 19200
8 hex: 38400
9 hex: 57600
A hex: 115200
Retained See
Function
column.
Refreshed
when power is
turned ON.
12
to
15
Communication
mode
0 hex: Default (Host
Link)
3 hex: Non-protocol
5 hex: Host Link
7 hex: Serial PLC
Link (Slave)
8 hex: Serial PLC
Link (Master)
9 hex: Modbus-RTU
Easy Master
Retained See
Function
column.
Refreshed
when power is
turned ON.
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
