Bit 15 Bit 00
0Ć000
0Ć000
CHANNEL 00
0Ć000
CHANNEL DR 01
cD01 MON
0000010101010101
cD01 CHG?
000010101010101
cD01 CHG?
1 00010101010101
cD01 CHG?
10 0010101010101
cD01 CHG?
100 010101010101
cD01 CHG?
1000 10101010101
cD01 CHG?
100 010101010101
cD01 CHG?
10 0010101010101
cD01 MON
1000010101010101
4-2 Memory Card Initialization
The Programming Console provides a slot for a Memory card to allow the
backup of programs. Only one model of Memory Card, HMC-ES141, may be
used. Each Memory Card has 16 Kbytes of S-RAM. A battery is built-in to the
Memory Card to allow the data to be retained. One Memory Card can hold
up to 27 SP10 programs or 18 SP16 or SP20 programs.
A program can be saved to a full memory card and read out, but an error
message (“ERR CARD FULL”) will be displayed when the corrected file is
saved again.
After inserting a new Memory Card into the Programming Console, the Card
must be initialized using the following key sequence.
Key Sequence
The corresponding displays are shown following.
Example
Initialization Procedure
Memory Card Initialization Section 4-2
To Next Page
