Appendix B
Specifications
General Ratings
Item
SP__-D_-A SP__-D_-D*
Power supply voltage 100 to 240 VAC, 50/60 Hz 24 VDC
Operating voltage range 85 to 264 VAC 20.4 to 26.4 VAC
Power consumption 30 VA max. 10 W max.
24-VDC output terminal SP10 0.1 A max. at 24 VDC ±10% None
SP16 and SP20 0.2 A max. at 24 VDC ±10%
Insulation resistance 20 MΩ (at 500 VDC) between current-carrying and noncurrent-carrying metal parts
Dielectric strength 2,300 VAC, 50/60 Hz for 1 min between current-carrying and noncurrent-carrying
metal parts
Noise immunity 1,000 V
p-p
with 100-ns to 1-µs pulse width and 1-ns pulse rise
Vibration resistance 10 to 58 Hz with 0.15-mm double amplitude or 58 to 150 Hz (1G) for 80 min in X, Y, Z
directions (JIS C0911)
Shock resistance Destruction: 10G three times in X, Y, Z directions (JIS C0912)
Ambient operating temperature 0° to 55°C (Programming Console: 0° to 45°C)
Ambient operating humidity 10% to 90% (with no condensation)
Ambient atmosphere No corrosive gases
Ambient storage temperature –20°to 75°C (Programming Console: –20% to 65°C)
Structure Control panel mountable (IP30)
Weight SP10 500 g max.
SP16 600 g max.
SP20 700 g max.
Dimensions SP10 92 x 68 x 81 (W x H x D) without cables
SP16 135 x 68 x 81 (W x H x D) without cables
SP20 160 x 68 x 81 (W x H x D) without cables
*Note: Do not use normally closed contacts for inputs to models that run on DC power. Doing so can cause
counters and shift registers to be reset and bits programmed with KEEP(12) to reverse status during
power interruptions.
Input Specifications
Input voltage 24 VDC
+10%
/
–15%
Input impedance 3.3 kΩ
Input current 7 mA typ. (at 24 VDC)
ON voltage 15 VDC min.
OFF voltage 5 VDC max.
ON/OFF delays ON: 200 µs max.
OFF: 250 µs max.
No. of inputs SP10 6 points (1 circuit)*
SP16 10 points (1 circuit, 8 pts; 1 circuit, 2 pts)*
SP20 12 points (1 circuit, 8 pts; 2 circuits, 2 pts each)*
*The common terminal can be connected either as + or –.
