3-5
Noise Measurement Window
The Noise Measurement Window allows you to continuously send the "NOISE MEASUREMENT
command" to the Amplifier Unit and display the results in real time.
The horizontal axis gives the time and the vertical axis gives the noise level (0 to 99).
Peak noise level Start/Stop Button
Graph Clear Button
3 V640 Utility Tool Features
3-11
V640 SERIES CIDRW SYSTEM OPERATION MANUAL V640 Utility Tool (Z469-E1)
3-5 Noise Measurement Window
3
