Omron ZEN Quick Guide

6 Creating the Program ZEN Programmable Logic Module
OMRON ELECTRONICS, S.A. Page 17
6. Creating the Program
This section gives a step-by-step explanation of how to implement a simple
contact diagram or circuit on ZEN, and the programming from the display. The
circuit to be used is the following:
6.1. I/O Wiring
6.2. Clearing the Programs
Clear the program before you start writing the
program. By using this option, neither the
language display, the date/time nor the other
settings will be initialized.
OK (1)
OK (1) + ⇓
⇓⇓
⇓ (2)
OK (1)
OK (1)
• STOP Mode

Omron ZEN Specifications

General

Display	LCD
Mounting Type	DIN Rail
Operating Temperature	-10 to 55°C
Power Supply Voltage	100-240V AC
Output Type	Relay, Transistor
Number of Outputs	4-8
Programming Language	Ladder Logic
