Omron ZFX-C Command Reference

About Communication Commands
54
ZFX-C Serial Communication Command Reference
Parameters for inspection by individual application
Grouping
Defect
Data No. Parameter Output Range
51 Search mode 0: Hi-speed, 1: Normal, 2: Precision
52 Verification 0: OFF, 1: ON
53 Candidate level 0 to 100
54 Calibration 0: OFF, 1: ON
55 Coordinates mode 0: Normal, 1: Pos. correction
71 Correlation upper limit value 0 to 100
72 Correlation lower limit value 0 to 100
73 X upper limit value -9999.999 to 9999.999
74 X lower limit value -9999.999 to 9999.999
75 Y upper limit value -9999.999 to 9999.999
76 Y lower limit value -9999.999 to 9999.999
77 Index No. upper limit value 0 to 63
78 Index No. lower limit value 0 to 63
Data No. Parameter Output Range
52 Detection size 4 to 64
53 Detection interval 4 to 64
54 Noise level 0 to 255
55 Calibration 0: OFF, 1: ON
56 Coordinates mode 0: Normal, 1: Pos. correction
71 Defect 0 to 255
72 Density upper limit value 0 to 255
73 Density lower limit value 0 to 255
74 Number of defects upper limit value 0 to 255
75 Number of defects lower limit value 0 to 255
