Laser Safety
vii
Interlocks on Protective Housing
(4.3.2)
✩✩✩✩XX
Service Access Panel (4.3.3) ✩✩✩✩XX
Key Control (4.3.4) --- --- --- --- • X
Viewing Portals (4.3.5.1) --- --- MPE MPE MPE MPE
Collecting Optics (4.3.5.2) MPE MPE MPE MPE MPE MPE
Totally Open Beam Path (4.3.6.1) --- --- --- --- X
NHZ
X
NHZ
Limited Open Beam Path (4.3.6.2) --- --- --- --- X
NHZ
X
NHZ
Enclosed Beam Path (4.3.6.3) None is required if 4.3.1 and 4.3.2 fulfilled
Remote Interlock Connector
(4.3.7)
--- --- --- --- • X
Beam Stop or Attenuator (4.3.8) --- --- --- --- • X
Activation Warning Systems
(4.3.9)
--- --- --- --- • X
Emission Delay (4.3.9.1) --- --- --- --- --- X
Indoor Laser Controlled Area
(4.3.10)
--- --- --- --- X
NHZ
X
NHZ
Class 3b Laser Controlled Area
(4.3.10.1)
--- --- --- --- X ---
Class 4 Laser Controlled Area
(4.3.10.2)
--- --- --- --- --- X
Laser Outdoor Controls (4.3.11) --- --- --- --- X
NHZ
X
NHZ
Laser in Navigable Airspace
(4.3.11.2)
--- --- --- • • •
Temporary Laser Controlled Area
(4.3.12)
✩
MPE
✩
MPE
✩
MPE
✩
MPE
--- ---
Remote Firing & Monitoring
(4.3.13)
--- --- --- --- --- •
Labels (4.3.14 and 4.7) XXXXXX
Area Posting (4.3.15) --- --- --- • X
NHZ
X
NHZ
Administrative & Procedural Con-
trols
12a23a3b4
Standard Operating Procedures
(4.4.1)
--- --- --- --- • X
Output Emission Limitations (4.4.2) --- --- --- LSO Determination
Education and Training (4.4.3) --- --- • • X X
Authorized Personnel (4.4.4) --- --- --- --- X X
Alignment Procedures (4.4.5) --- --- X X X X
Protective Equipment (4.4.6) --- --- --- --- • X
Spectator (4.4.7) --- --- --- --- • X
Service Personnel (4.4.8) ✩
MPE
✩
MPE
✩
MPE
✩
MPE
XX
Demonstration with General Public
(4.5.1)
MPE ✝ ---XXXX
Laser Optical Fiber Systems
(4.5.2)
MPE MPE MPE MPE X X
Laser Robotic Installations (4.5.3) --- --- --- --- X
NHZ
X
NHZ
Control measures Classification
