FUN (Function) Mode Section 4-5
138
4-5-12 Other Special FUN Mode Settings
The following “other” items can be set when or is selected
in the special FUN mode settings
Settings for
non-measurement
Zero reset memory
function
Gain setting
Output value held
Current: About 23 mA
Voltage: Clamped at
about 5.5 V (fix
ed)
Go to the next
mode.
Enabled
Disabled
Black mode
White mode
Metal mode
Auto
(See note.)
Note: This function can be set only for a
Reflective Sensor.
Z157-E1-01C.book Page 138 Thursday, August 31, 2006 5:13 PM
