Appendix A - Console Cable
Catalog reference: 4 022 332 B 00 Ed A
P2
P1
To P C
in terminal
mode
serial port
(Configuration)
RJ45 - P1 SIGNAL SUB-D 9 Pts
Female - P2
1 TX 2
2 RX 3
3 GND 5
