ONECELL25 - Installation Manual
5
1 Safety Instructions
The following symbol instructs the user to read the manual carefully before any
connection:
1.1 Connection to Power Supply
To connect the power supply, always follow these steps:
• Connect the DC input jack from the power supply to the DC 12V power input
on the rear panel of the router,
• Connect the power supply to an AC electrical outlet (200-240 VAC). Plugging
in the power supply turns on the router.
Unplug the AC input before assembling/disassembling any part on the
device. The AC input is the part you must disconnect first. For safety rea-
sons, you shall be able to easily access this part.
1.2 Overcurrent Protection
The product requires that the building’s electrical installation is designed for
protection against short-circuit (over current) protection.
A fuse or circuit breaker no larger than 240 VAC, 10A must be used on the phase
conductors.
1.3 Safety Level of Interfaces
1.3.1 LAN Interface 10/100 Mbps (FASTETHERNET)
This section is related to interfaces whose marking on the router back panel is:
FASTETHERNET.
The Ethernet 100 Mbps auto-sense has a ’SELV’ (Safety Extra Low Voltage)
interface.
They must be used only for indoor applications, connected to a 100 Mbps interface,
which has also the ’SELV’ characteristics.
