Assembly Instructions (Continued)
Installation is complete! Plug in your collector
and turn on the rocker switch mounted on the
motor. [FIG. 16]
Note: Refer to the FAQ section for suggestions on
how to connect your collector to your layout.
16
FIG. 16
FIG. 15
e Mini-Gorilla requires a 20 Amp outlet
receptacle to be installed by a licensed
electrician. Review outlet receptacles shown in
[FIG. 15] based on the voltage of your unit.
Note: e Mini-Gorilla should run on a dedicated
circuit that is adequately sized for its amperage
and voltage requirements.
15
The Mini-Gorilla requires a 20 Amp outlet receptacle to be installed by a licensed electrician.

120V / 16A Mini-Gorilla
#XXPM010100H
Use NEMA 5-20
Receptacles
Use NEMA 6-20
Receptacles
220V / 8A Mini-Gorilla
#XXPM010100H220
