System-10-LON Network Interface Installation Guide 07/13 - 0654-4 / 16751 Page 13
NODE OBJECT REQUESTS
Node Object
Requests
Function
Blocks
Affected
Comments
RQ_NORMAL 0-27 This request clears the status registers. Function block 0 clears
all function block status registers. Selecting function blocks 1- 27
only clears the selected status register.
RQ_UPDATE_MASK 0-27 This request updates the selected status register.
RQ_REPORT_MASK 0-27 This request displays the available Object Status functions.
RQ_RESET 0, 3, 6, 17,
21, 27
This request zeroes the various ow, energy and auxiliary pulse
totals. If the Object ID 0 request RQ_RESET is selected then all
totals are cleared. If the Object ID of 3, 6, 17, 21 or 27 RQ_RESET
is selected then only the appropriate total is cleared.
RQ_CLEAR_RESET 0, 3, 6, 17,
21, 27
This request clears reset status ags. Object ID of 0 clears all
“reset_complete” ags. Object IDs 3, 6, 17, 21, 27: Clears the
selected “reset_complete” ags.
SELECT FUNCTION BLOCKS, BTU METER TOTALS & BTU METER OPERATING MODES
Functional
Block
Btu Meter Total
Btu Meter Operating Mode
Single Dual Bidirectional
3 Flow (volume) - 1 Heat or Cool Heating Forward Flow
6 Flow (volume) - 2 Inactive Cooling Reverse Flow
17 Energy-1 Heat or Cool Heating Forward Flow
21 Energy-2 Inactive Cooling Reverse Flow
27 Auxiliary Pulse (Di3) Active Active Active
1.7.4.2 nvoStatus
Six status object functions are mechanized to report status information to
the network. These are listed in the table below. The table also lists
function blocks associated with each status ag.
nvoStatus Object Functions Functional Blocks
object_id All
invalid_id All
invalid_request All
comm_failure 0
report_mask All
reset_complete 0, 3, 6, 17, 21, 27
1.7.5 Resetting Totals via the Network
Totals are held in non-volatile memory within the Btu meter. Each total (ow, energy or
auxiliary input) has a corresponding output variable that transmits the information from
the meter to the network. There are two ways to remotely reset totals in the display. This
can be done using individual input variables to command the display to reset specic
totals or it can be done using the nviRequest variable. Using nviRequest allows you to
reset each total individually or all totals simultaneously with one command. See sections
1.7.3 and 1.7.4.1 for specic instructions on how to reset totals.
