Page #15 background image
1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com
System-10-LON Network Interface Installation Guide 07/13 - 0654-4 / 16751 Page 15
SECTION 2.0: NETWORK TROUBLESHOOTING TIPS
2.1 TROUBLESHOOTING
REPORTED PROBLEM POSSIBLE SOLUTIONS
For turbine meters -
No Flow Signal/ Energy Rate
(while hydronic system is
active)
Verify 24 VDC supply voltage to the ow meter.
For insertion meters, verify the ow meter is correctly inserted
into the pipe (using depth gage).
For insertion meters, verify that the ow meter electronics
enclosure is parallel with the pipe.
Verify correct wiring to the ow meter (see wiring diagram).
For turbine meters, check turbine(s) for clogging due to debris.
If none of the above, check hydronic system to ensure that ow is
really present in the line.
NOTE: Flow meter function cannot be veried by blowing on the
turbine(s). The sensing system requires a conductive liquid to
operate. You can test it by swirling it around in a bucket of water
and looking for the ow indicator LED to ash at the System-10.
Displayed ow rate too high
or too low
Verify pipe size. Contact ONICON if pipe size is different from
calibration tag.
For insertion meters, verify that meter is inserted correctly into the
pipe (using depth gage).
For insertion meters, verify that the ow meter electronics
enclosure is parallel with the pipe.
For dual turbine meters, conrm that both turbines produce
pulses.
For turbine meters, check turbine(s) for debris.
Verify supply voltages (to Btu meter and ow meter).
Displayed temperature(s) too
high or too low vs. expected
values
Verify wiring to temperature sensor(s), including polarity.
Verify that thermowells are inserted into the ow stream and
that the temperature sensors are completely inserted into the
thermowells.
Device is not communicating
with the Lon Talk network.
What is the state of the service pin LED?
Is it ashing? A ashing service pin LED indicates that the Lon
module has not been commissioned.
Is it off? A service pin LED that is off indicates that the Lon
module is commissioned and operating normally.
Communications with
the Lon Talk network is
intermittent.
Is the network properly terminated? The Lon TP/FT bus can be
terminated in 2 different ways.
A single RC lter can installed at any point on a free topology
network. A dual termination scheme is used with 2 RC lters
installed at the ends of bus networks. Refer to the Appendix A-6
for details.
What type of cable is used to wire the network? TP/FT networks
should only use twisted shielded pair cable. (Belden 85102 or
equiv.)
For technical assistance, contact ONICON at (727) 447-6140.
