Onkyo A-5VL

Appendix
18
Specifications
Rated output Power : North America
40 watts minimum continuous power per channel, 8 ohm loads, 2
channels driven at 1 kHz, with a maximum total harmonic
distortion of 0.8 % (FTC)
100 watts minimum continuous power per channel, 2 ohm loads, 2
channels driven at 1 kHz, with a maximum total harmonic
distortion of 0.8 % (FTC)
Europe and Taiwan
40 W at 8 ohms, 2 ch driven, 1 kHz, 0.8 % THD (IEC)
80 W at 4 ohms, 2 ch driven, 1 kHz,0.8 % THD (IEC)
China
35 W at 8 ohms, 2 ch driven, 1 kHz, 0.7 % THD (IEC)
60 W at 4 ohms, 2 ch driven, 1 kHz, 0.7 % THD (IEC)
Maximum Output Power : China and Taiwan
90 W at 4 ohms, 1 kHz, 2 ch driven (JEITA)
Dynamic Power : 115 W (3 , Front)
90 W (4 , Front)
45 W (8 , Front)
THD (Total Harmonic Distortion) : 0.08 % (1 kHz 1 W)
Damping Factor : 60 (Frontޔ1 kHzޔ8 )
Input Sensitivity and Impedance : 200 mV/33 k(LINE)
2.4 mV/47 k(PHONO MM)
Output Level and Impeadance : 200 mV/2.2 k(REC OUT)
Phono Overload : 60 mV (MM 1 kHz 0.5 %)
6.0 mV (MC 1 kHz 0.5 %)
Frequency Response : 5 Hz-60 kHz/+1 dB-3 dB (LINE)
Tone Control : +14 dB, -14 dB, 100 Hz (BASS)
+12 dB, -12 dB, 10 kHz (TREBLE)
+0 dB, -12 dB (BALANCE)
Signal to Noise Ratio : 100 dB (LINE, IHF-A)
65 dB (PHONO, IHF-A)
Speaker Impedance : North America and Taiwan
2  㨪 16 (A or B), 4  㨪 16 (A + B)
Others
4  㨪 16 (A or B), 8  㨪 16 (A + B)
Digital Inputs : OPTICAL 1 (Rear), COAXIAL 1 (Rear)
Analog Inputs : PHONO/CD/TUNER/TAPE/DOCK
Analog Outputs : TAPE
Speaker Outputs : 2 (A, B)
Phones : 1
Power Supply : North America and Taiwan AC 120 V, 60 Hz
Others AC 220-240 V, 50/60 Hz
Power Consumption : North America and T
aiwan 110 W
Others 75 W
Dimensions (WxHxD) : 435 x 80 x 340 mm
17-1/8"×3-1/8"×13-3/8"
Weight : 10.2 kg (22.5 lbs)
Specifications and features are subject to change without notice.
