Onkyo CR-N775D User Manual

> Before Start > Part Names > Install > Initial Setup >Playback
Supplementary information | Advanced Setup | Others
11
En
To make Wi-Fi settings, select "Yes". Select the method
for setting in the next screen (for example "Scan
Networks").
∫ Scan Networks
From the list of SSID for access points such as wireless
LAN routers, select the required SSID and make the
settings.
1. Select the SSID of the access point you want to
connect and then confirm.
2. Select either "Enter Password" or "Push Button" and
confirm. If the access point has an automatic setting
button, by selecting "Push Button" you can connect
without entering a password.
3. If you select "Enter Password", enter the password
of the access point. For details on how to enter text,
refer to "Entering text" (ÄP36).
If you select "Push Button", then after pressing and
holding the automatic setting button on the access
point for the required amount of time, press ENTER
on the remote controller.
4. is displayed when the settings are complete.
∫ Use iOS Device
Set by sharing the iOS device's Wi-Fi settings with this
unit.
1. Connect the iOS device by Wi-Fi.
2. Select this unit in the "SET UP NEW AIRPLAY
SPEAKER..." item in the Wi-Fi setting screen of the
iOS device, then select "Next".
0 This unit is displayed as "Onkyo CR-N775D
XXXXXX".
3. After establishing the connection, select "Done" on
the screen of the iOS device.
4. is displayed when the settings are complete.
∫ Enter SSID of the access point
Set by entering the SSID of the access point you want
to connect.
1. Enter the SSID. For details on how to enter text,
refer to "Entering text" (ÄP36).
2. Select and confirm the authentication method.
0 If you select "None", proceed to step 3. If you
select "WEP", "WPA", or "WPA2", enter the
password and confirm.
3. is displayed when the settings are complete.
Initial Setup
Yes
No
Would you like to start Wi-Fi setup?
Wi-Fi Setup
Scan Networks
Use iOS Device
Input SSID
Asb
Wi-Fi Setup
aaaaaaaaaaaaaaa
bbbbbbbbbbbbbbb
cccccccccccccccc
ddddddddddddddd
Asb
Wi-Fi Setup
Enter Password
Push Button
Asb
Password
A/a OK
MEMORY
Hide/Show
SSID
A/a OK
Security Method
None
WEP
WPA
WPA2
Asb

Onkyo CR-N775D Specifications

General

Receiver type	-
Input sensitivity	400 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Power output per channel (20-20KHz@8 Ohm)	- W
USB ports quantity	2
Digital audio optical in	1
Display	LCD
Apple docking	No
Product color	Black
Center speaker impedance	16 Ω
Connector contacts plating	Gold
Headphone connectivity	3.5 mm
Audio formats supported	ALAC, CBR, DSD, FLAC, MP3, MP3 VBR, MQA, WAV
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Internet radio services supported	Deezer, Spotify, Tidal, TuneIn
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2.9 W
Power consumption (typical)	36 W
Package weight	3800 g
Cables included	AC
Package depth	276 mm
Package width	345 mm
Package height	235 mm

Weight and Dimensions

Depth	295 mm
Width	215 mm
Height	117 mm
Weight	2700 g
