Onkyo CR-N775D User Manual

> Before Start > Part Names > Install > Initial Setup >Playback
Supplementary information | Advanced Setup | Others
10
Power On & Initial Setup
Initial Setu p
2
1
3
2
Starting up: When you press the Í button, the volume
indicator on the main unit lights white, then after
30 seconds the ONKYO logo is displayed on the
display and you can start operating the unit.
Wi-Fi connection settings
When you first turn the power on, the initial setup
screen is displayed automatically, allowing you to
easily make Wi-Fi connection settings.
0 To redo the initial settings, press on the remote
controller, select "Wi-Fi" in "Network" - "Connection
Type", then select "Wi-Fi Setup".
0 A confirmation screen asking you to agree to the
privacy policy is displayed during network setting.
Select "Accept" and press ENTER to indicate
agreement.
To set, select the item with the cursors on the remote
controller and press ENTER to confirm (a). To return to
the previous display, press (b).
a
b

Onkyo CR-N775D Specifications

General

Receiver type	-
Input sensitivity	400 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Power output per channel (20-20KHz@8 Ohm)	- W
USB ports quantity	2
Digital audio optical in	1
Display	LCD
Apple docking	No
Product color	Black
Center speaker impedance	16 Ω
Connector contacts plating	Gold
Headphone connectivity	3.5 mm
Audio formats supported	ALAC, CBR, DSD, FLAC, MP3, MP3 VBR, MQA, WAV
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Internet radio services supported	Deezer, Spotify, Tidal, TuneIn
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2.9 W
Power consumption (typical)	36 W
Package weight	3800 g
Cables included	AC
Package depth	276 mm
Package width	345 mm
Package height	235 mm

Weight and Dimensions

Depth	295 mm
Width	215 mm
Height	117 mm
Weight	2700 g
