Onkyo CR-N775D User Manual

> Before Start > Part Names > Install > Initial Setup >Playback
Supplementary information | Advanced Setup | Others
26
BLUETOOTH
®
Playback
Pairing
Perform the following procedure when the unit is on.
1. When you press the button on the remote
controller, "Now Pairing..." is displayed on the
display, and the pairing mode is enabled.
2. Enable (turn on) the BLUETOOTH function of the
BLUETOOTH wireless technology enabled device,
then select this unit from amongst the devices
displayed. If a password is requested, enter "0000".
0 This unit is displayed as "Onkyo CR-N775D
XXXXXX".
3. "Now Pairing..." on the display changes to the name
of the BLUETOOTH wireless technology enabled
device.
0 To connect another BLUETOOTH wireless
technology enabled device, press and hold the
button until "Now Pairing..." is displayed, then
perform step 2 above. This unit can store the data of
up to eight paired devices.
0 The coverage area is within about 32y/10 m. Note
that connection is not always guaranteed with all
BLUETOOTH wireless technology enabled devices.
Playing Back
Perform the following procedure when the unit is on.
1. Perform the connection procedure on the
BLUETOOTH wireless technology enabled device.
2. The input selector on this unit automatically switches
to BLUETOOTH.
3. Play the music files. Increase the volume of the
BLUETOOTH wireless technology enabled device to
an appropriate level.
0 Due to the characteristics of BLUETOOTH wireless
technology, the sound produced on this unit may
slightly be behind the sound played on the
BLUETOOTH wireless technology enabled device.
OnkyoCR-N775D
1
2
3
BLUETOOTH
Asb
Now Pairing...
--:--:-- / --:--:--

Onkyo CR-N775D Specifications

General

Receiver type	-
Input sensitivity	400 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Power output per channel (20-20KHz@8 Ohm)	- W
USB ports quantity	2
Digital audio optical in	1
Display	LCD
Apple docking	No
Product color	Black
Center speaker impedance	16 Ω
Connector contacts plating	Gold
Headphone connectivity	3.5 mm
Audio formats supported	ALAC, CBR, DSD, FLAC, MP3, MP3 VBR, MQA, WAV
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Internet radio services supported	Deezer, Spotify, Tidal, TuneIn
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2.9 W
Power consumption (typical)	36 W
Package weight	3800 g
Cables included	AC
Package depth	276 mm
Package width	345 mm
Package height	235 mm

Weight and Dimensions

Depth	295 mm
Width	215 mm
Height	117 mm
Weight	2700 g
