Onkyo FR-V3 User Manual

4
Main features
• CD/MD Receiver with Simple and Easy Operation
• Easy Dubbing from CD to MD
• Discrete Amplifier for Good Sound Quality
• Three Source Inputs – TAPE, LINE-1, and LINE-2
• Optical Digital Source Input & Digital Input Signal
Sampling Frequency Rate Converter
• Signal Synchro Recording that is also associated
with the external sources connected to the unit.
Supplied accessories
Check that the following accessories are supplied
with your CD/MD Receiver.
The number of accessories is indicated in brackets.
• Remote controller – RC-378S [1]
• Batteries (size AA/R6) [2]
• Indoor antenna (aerial) [1]
• Instruction Manual – this manual [1]
Main features/
Supplied accessories
For British model
Replacement and mounting of an AC plug on the power supply cord
of this unit should be performed only by qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance with the
following code:
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this apparatus may
not correspond with the coloured markings identifying the terminals
in your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal
which is marked with the letter L or coloured red.
IMPORTANT
A 5 amp fuse is fitted in this plug. Should the fuse need to be replaced,
please ensure that the replacement fuse has a rating of 5 amps and
that it is approved by ASTA or BSI to BS1362. Check for the ASTA
mark or the BSI mark on the body of the fuse.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE
SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE
REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE
CUT OFF PLUG IS INSERTED INTO ANY 13 AMP SOCKET.
If in any doubt, please consult a qualified electrician.
Declaration of Conformity
We,
ONKYO EUROPE
ELECTRONICS GmbH
INDUSTRIESTRASSE 20
82110 GERMERING,
GERMANY
declare in own responsibility, that the ONKYO product described
in this instruction manual is in compliance with the corresponding
technical standards such as EN55013, EN55020, EN61000-3-2, -3-3
and EN60065
GERMERING, GERMANY
ONKYO EUROPE ELECTRONICS GmbH
K.OTSU
Precautions
Memory Preservation
This unit does not require memory preservation
batteries. A built-in memory power back-up system
preserves the contents of the memory during power
failures and even when the unit is unplugged. The unit
must be plugged in order to charge the back-up system.
The memory preservation period after the unit has been
unplugged varies depending on climate and placement
of the unit. On the average, memory contents are
protected over a period of a few weeks after the last time
the unit has been unplugged. This period is shorter when
the unit is exposed to a highly humid climate.
Das private Onkyo Archiv © von Dirk Gardi
Der Online-Treff zum Thema Onkyo!
www.gardi.de
Das private Onkyo Archiv © von Dirk Gardi
Der Online-Treff zum Thema Onkyo!
www.gardi.de
Das private Onkyo Archiv © von Dirk Gardi
Der Online-Treff zum Thema Onkyo!
www.gardi.de

Onkyo FR-V3 Specifications

Power

power supply	AC 230 V, 50 Hz AC 120 V, 60 Hz
power consumption	66 W

Amplifier Specifications

power output at 4 Ω 1kHz DIN	2 × 20 W
power output at 6 Ω 1kHz DIN	2 × 17 W
power output at 8 Ω 1kHz DIN	2 × 15 W
dynamic power at 4 Ω	2 × 24 W
dynamic power at 8 Ω	2 × 18 W

Tuner Specifications

tuning range	87.50 to 108.00 MHz (50 kHz steps)
usable sensitivity mono	12.8 dBf, 1.2 µV (75 Ω IHF) 1.0 µV (75 Ω DIN)
usable sensitivity stereo	18.0 dBf, 2.2 µV (75 Ω IHF) 25.0 µV (75 Ω DIN)

Weight and Dimensions

dimensions	205 × 154 × 356 mm
weight	5.5 kg
