Onkyo HT-R380 Service Manual

A
340 COVE
R
(
B
)
(
Not Bent
)
1 28210031Z
(
B
)
<MDC>
A342 SCREW 3TTB+8B(3BC) 7 NSP
（B)
A
350 PLATE
(
COVER
)
B1 NSP
(
B
)
<MMQ>
A354 HOLDER (PLATE) 6 NSP
(B）<MMQ>
A
360 LABEL
(
COVER
)
1 NSP
A
362 LABEL HOOKUP-ONKYO 1 NSP <MDC>
[
TUNER UNIT
]
U001
A
F-AS (AMPLIFIER)
(U0010/11/12/13/14/15)
BAAF-0341-1D * 1 1B247541-1D N <MDC>
U001
A
F-AS (AMPLIFIER)
(
U0010/11/12/13/14/15
)
BAAF-0341-1E * 1 1B247541-1E N <MPP>
U001
A
F-AS (AMPLIFIER)
(
U0010/11/12/13/14/15
)
BAAF-0341-1F * 1 1B247541-1F N <MMO,MMQ>
U0010 AF-AS (AMPLIFIER) BAAF-0341-1D 1 1B2475341-1D N <MDC>
U0010 AF-AS (AMPLIFIER) BAAF-0341-1E 1 1B2475341-1E N <MPP>
U0010 AF-AS (AMPLIFIER) BAAF-0341-1F 1 1B2475341-1F N <MMO,MMQ>
U0011 PWB (FL TUBE -VP) BAPS-0342-1D 1 1B2475342-1D N <MDC>
U0011 PWB (FL TUBE -VP) BAPS-0342-1E 1 1B2475342-1E N <MPP>
U0011 PWB (FL TUBE -VP) BAPS-0342-1F 1 1B2475342-1F N <MMO,MMQ>
U0012 PWB (TEMP-SEN) BAETC-0343-1D 1 1B2475343-1D N <MDC>
U0012 PWB (TEMP-SEN) BAETC-0343-1E 1 1B2475343-1E N <MPP>
U0012 PWB (TEMP-SEN) BAETC-0343-1F 1 1B2475343-1F N <MMO,MMQ>
U0013 PWB BAETC-0344-1D 1 N NSP <MDC>
U0013 PWB BAETC-0344-1E 1 N NSP <MPP>
U0013 PWB BAETC-0344-1F 1 N NSP <MMO,MMQ>
U0014 PWB (TRANS-TRM) BAETC-0345-1D 1 1B2475345-1D N <MDC>
U0014 PWB (TRANS-TRM) BAETC-0345-1E 1 1B2475345-1E N <MPP>
U0014 PWB (TRANS-TRM) BAETC-0345-1F 1 1B2475345-1F N <MMO,MMQ>
U0015 PWB BAETC-0346-1D 1 N NSP <MDC>
U0015 PWB BAETC-0346-1E 1 N NSP <MPP>
U0015 PWB BAETC-0346-1F 1 N NSP <MMO,MMQ>
U003 DG-AS(MPU/DAC ASSY) BADG-0364-1C *
1 1B247564-1C N <MMO, MMQ>
U003 DG-AS(MPU/DAC ASSY) BADG-0364-1D * 1 1B247564-1D N <MDC>
U003 DG-AS(MPU/DAC ASSY) BADG-0364-1E * 1 1B247564-1E N <MPP>
U0030 DG-AS(MPU/DAC) BADG-0364-1C 1 1B2475364-1C N <MMO, MMQ>
U0030 DG-AS(MPU/DAC) BADG-0364-1D 1 1B2475364-1D N <MDC>
U0030 DG-AS(MPU/DAC) BADG-0364-1E 1 1B2475364-1E N <MPP>
U0031 PWB(U-PORT) BAETC-0365-1C 1 1B2475365-1C N <MMO, MMQ>
U0031 PWB(U-PORT) BAETC-0365-1D 1 1B2475365-1D N <MDC>
U0031 PWB(U-PORT) BAETC-0365-1E 1 1B2475365-1E N <MPP>
U004 DIS-AS(DISPLAY ASSY) BADIS-0373-1C * 1 1B247573-1C N <MDC>
U004 DIS-AS(DISPLAY ASSY) BADIS-0373-1D * 1 1B247573-1D N <MPP, MMO, MMQ>
U0040 DIS-AS(DISPLAY) BADIS-0373-1C 1 1B2475373-1C N <MDC>

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
