Onkyo HT-R380 Service Manual

A808 INS MANUAL Ar(QC ImportantSheet) 1 29344373 HT-S3300 < MMQ>
A810 INS MANUAL En(QSS HT-S3300) 1 29400210
N
HT-S3300 <MDC, MMO, MMQ>
A810 INS MANUAL En(QSS HT-S3305) 1 29400262
N
HT-S3305 <MPP>
A811 INS MANUAL En(HT-R380MPP) 1 29400408
N
HT-S3305 AVX-380 <MPB, MPP>
A812 INS MANUAL U2FrEs(HT-R380MPP) 1 29400409
N
HT-S3305 AVX-380 <MPP>
A813 INS MANUAL En(QSS AVX-380) 1 29400410
N
HT-S3305 AVX-380 <MPB, MPP>
A814 INS MANUAL U3DaFiNo(HT-R380) 1 29400411
N
AVX-380 <MPP>
A826 INST SHEET U11(2010_RIHD) 1 29355782
A830 INST SHEET WEEE 1 29355537A AVX-380 <MPB, MPP>
A830 INST SHEET WEEE 1 29355537B HT-S3305 <MPP>
A835 HANDBILL (UP-A1)US 1 29380155 HT-S3300 <MDC>
A835 HANDBILL (UP-A1)EU 1 29380156 HT-S3305 AVX380 <MPB, MPP>
A855 REMO CON RC-762M 1 24140762
A858 ANT COIL NMA-3057 1 232140
A859 FM ANT AS Type W 1 292191
A861 BATTERY R6/AA(UM-3) 2 3010194
A861or BATTERY R6/AA(UM-3) ( 2) 3010054
A884 WRNTY CARD MGQ 1 29365099A HT-S3300 <MMQ>
A885 WRNTY CARD (ONKYO) 1 29365135 HT-S3300 <MDC>
HT-R380
PC BOARD PARTS LIS
T
U001
AF-AS (AMPLIFIER ASSY)
(U0010/11/12/13/14/15)
BAAF-0341-1D * 1 1B247541-1D N <MDC>
U001
AF-AS (AMPLIFIER ASSY)
(U0010/11/12/13/14/15)
BAAF-0341-1E * 1 1B247541-1E N <MPB, MPP>
U001
AF-AS (AMPLIFIER ASSY)
(U0010/11/12/13/14/15)
BAAF-0341-1F * 1 1B247541-1F N <MMO,MMQ>
U0010
A
F-AS
(
AMPLIFIER
)
BAAF-0341-1D 1 1B2475341-1D N <MDC>
U0010
A
F-AS
(
AMPLIFIER
)
BAAF-0341-1E 1 1B2475341-1E N <MPB, MPP>
U0010
A
F-AS
(
AMPLIFIER
)
BAAF-0341-1F 1 1B2475341-1F N <MMO,MMQ>
U0011
PWB
(
FL TUBE -VP
)
BAPS-0342-1D 1 1B2475342-1D N <MDC>
U0011
PWB
(
FL TUBE -VP
)
BAPS-0342-1E 1 1B2475342-1E N <MPB, MPP>
U0011
PWB
(
FL TUBE -VP
)
BAPS-0342-1F 1 1B2475342-1F N <MMO,MMQ>
U0012
PWB
(
TEMP-SEN
)
BAETC-0343-1D 1 1B2475343-1D N <MDC>
U0012
PWB
(
TEMP-SEN
)
BAETC-0343-1E 1 1B2475343-1E N <MPB, MPP>
U0012
PWB
(
TEMP-SEN
)
BAETC-0343-1F 1 1B2475343-1F N <MMO,MMQ>
U0013 PWB BAETC-0344-1D 1 N NSP <MDC>
U0013 PWB BAETC-0344-1E 1 N NSP <MPB, MPP>
U0013 PWB BAETC-0344-1F 1 N NSP <MMO,MMQ>
U0014
PWB
(
TRANS-TRM
)
BAETC-0345-1D 1 1B2475345-1D N <MDC>
U0014
PWB
(
TRANS-TRM
)
BAETC-0345-1E 1 1B2475345-1E N <MPB, MPP>
U0014
PWB
(
TRANS-TRM
)
BAETC-0345-1F 1 1B2475345-1F N <MMO,MMQ>
U0015 PWB BAETC-0346-1D 1 N NSP <MDC>
U0015 PWB BAETC-0346-1E 1 N NSP <MPB, MPP>
U0015 PWB BAETC-0346-1F 1 N NSP <MMO,MMQ>

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
