Page #35 background image
CIRCUIT. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D4171 ZENER D MTZJ6.2B 1 224470622T
D4172 ZENER D MTZJ6.2B 1 224470622T
D4173 DIODE 1SS133 1 223163T
D4174 DIODE 1SS133 1 223163T
D4300 DIODE RL1N4003 1 22380260T
D4300 or DIODE GP104003E ( 1) 22380035T
D4301 DIODE RL1N4003 1 22380260T
D4301 or DIODE GP104003E ( 1) 22380035T
D4302 DIODE RL1N4003 1 22380260T
D4302 or DIODE GP104003E ( 1) 22380035T
D4303 DIODE RL1N4003 1 22380260T
D4303 or DIODE GP104003E ( 1) 22380035T
D4304 DIODE 1SS133 1 223163T
D4305 DIODE 1SS133 1 223163T
D6020 C-DIODE KDS4148U 1 NSP
D6020 or C-DIODE 1SS352 ( 1) NSP
D6020 or C-DIODE MA2J111 ( 1) NSP
D6021 C-DIODE KDS4148U 1 NSP
D6021 or C-DIODE 1SS352 ( 1) NSP
D6021 or C-DIODE MA2J111 ( 1) NSP
D6022 C-DIODE KDS4148U 1 NSP
D6022 or C-DIODE 1SS352 ( 1) NSP
D6022 or C-DIODE MA2J111 ( 1) NSP
D6023 C-DIODE KDS4148U 1 NSP
D6023 or C-DIODE 1SS352 ( 1) NSP
D6023 or C-DIODE
MA2J111 ( 1) NSP
D6024 C-DIODE KDS4148U 1 NSP
D6024 or C-DIODE 1SS352 ( 1) NSP
D6024 or C-DIODE MA2J111 ( 1) NSP
D6027 C-DIODE KDS4148U 1 NSP
D6027 or C-DIODE 1SS352 ( 1) NSP
D6027 or C-DIODE MA2J111 ( 1) NSP
D6031 DIODE 1SS133 1 223163T
D6032 DIODE 1SS133 1 223163T
D6033 ZENER D UDZS3.3B 1 224550330R2
D6034 ZENER D UDZS3.3B 1 224550330R2
D6051 C-DIODE KDS4148U 1 NSP
D6051 or C-DIODE 1SS352 ( 1) NSP
D6051 or C-DIODE MA2J111 ( 1) NSP
