Onkyo HT-R380 Service Manual

PC BOARD PARTS LIS
T
U003 DG-AS
(
MPU/DAC ASSY
)
BADG-0364-1C * 1 1B247564-1C N <MMO, MMQ>
U003
DG-AS
(
MPU/DAC ASSY
)
BADG-0364-1D * 1 1B247564-1D N <MDC>
U003
DG-AS
(
MPU/DAC ASSY
)
BADG-0364-1E * 1 1B247564-1E N < MPB, MPP>
U0030
DG-AS
(
MPU/DAC
)
BADG-0364-1C 1 1B2475364-1C N <MMO, MMQ>
U0030
DG-AS
(
MPU/DAC
)
BADG-0364-1D 1 1B2475364-1D N <MDC>
U0030
DG-AS
(
MPU/DAC
)
BADG-0364-1E 1 1B2475364-1E N < MPB, MPP>
U0031
PWB
(
U-PORT
)
BAETC-0365-1C 1 1B2475365-1C N <MMO, MMQ>
U0031
PWB
(
U-PORT
)
BAETC-0365-1D 1 1B2475365-1D N <MDC>
U0031
PWB
(
U-PORT
)
BAETC-0365-1E 1 1B2475365-1E N < MPB, MPP>
CIRCUIT. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
U131 PHT CP JSR1165-001recieving 1 24120143
U132 PHT CP JSR1165-001recieving 1 24120143
[SEMI CONDUCTOR]
D110 C-DIODE KDS4148U 1 NSP
D110 or C-DIODE 1SS352 ( 1) NSP
D110 or C-DIODE MA2J111 ( 1) NSP
D111 C-DIODE KDS4148U 1 NSP
D111 or C-DIODE 1SS352 ( 1) NSP
D111 or C-DIODE MA2J111 ( 1) NSP
D112 ZENER D UDZS10B 1 224551000R2
D131 C-DIODE KDS4148U 1 NSP
D131 or C-DIODE 1SS352 ( 1) NSP
D131 or C-DIODE MA2J111 ( 1) NSP
D132 C-DIODE KDS4148U 1 NSP
D132 or C-DIODE 1SS352 ( 1) NSP
D132 or C-DIODE MA2J111 ( 1) NSP
D182 DIODE RL1N4003 1 22380260T
D183 DIODE RL1N4003 1 22380260T
D601 C-DIODE KDS4148U 1 NSP
D601 or C-DIODE 1SS352 ( 1) NSP
D601 or C-DIODE MA2J111 ( 1) NSP
D701 C-DIODE KDS4148U 1 NSP
D701 or C-DIODE 1SS352 ( 1) NSP
D701 or C-DIODE MA2J111 ( 1) NSP
D702 C-DIODE KDS4148U 1 NSP
D702 or
C-DIODE 1SS352 ( 1) NSP
D702 or C-DIODE MA2J111 ( 1) NSP
Q101 IC LC72725KV-TLM-E 1 22242584R2 <MMO, MMQ, MPB, MPP>
Q111 TR 2SC2235-Y(TPE6_F) 1 2211654T
Q131 IC TC74HCU04AF 1 222740046R2TO
Q131 or IC 74HCU04F ( 1) 222740046R2

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
