Onkyo HT-R380 Service Manual

JL954B WIRE HOL NSCT-9P900 1 25051113
P4000 ST JACK MSJ-035-22 1 25045887
P4000 or JACK YKB21-5130 ( 1) 25045387
P4002 PIN JACK NPJ-2PDWR595 1 25045815
P4003 PIN JACK NPJ-2PDWR558 1 25045776
P4003 or PIN JACK NPJ-2PDBL185 ( 1) 25045333
P4005 PIN JACK NPJ-4PDWWRR624 1 25045845
P4005 or PIN JACK NPJ-4PDBL162 ( 1) 25045303
P4006 PIN JACK NPJ-4PDWWRR624 1 25045845
P4006 or PIN JACK NPJ-4PDBL162 ( 1) 25045303
P5501B PLUG NPLG-7P0962 1 25056012
P5502B PLUG NPLG-15P0970 1 25056020
P5503B PLUG NPLG-9P0964 1 25056014
P5504B PLUG NPLG-7P0962 1 25056012
P6001 TRM NTM-12PDML362 1 25060433
P6001 or TRM NTM-12PDML356 ( 1) 25060427
P6002 TRM NTM-4PDMNRR420 1 25060492
P6900 CRIMP AS CRIMP AS 1 20799162UL
P6901 CRIMP AS CRIMP AS 1 2069925162UL
P6902 CRIMP AS CRIMP AS 1 2069925149UL
P6903 WS CLAMP CB-71683(L=50) 1 260261
P6906 WS CLAMP CB-71683(L=50) 1 260261
P6909 WS CLAMP CB-71683(L=50) 1 260261
P6913 WS CLAMP CB-71683(L=50) 1 260261
RL601 RELAY NRL-2P5A-DC12-192 1 25065702
RL602 RELAY NRL-2P5A-DC12-192 1 25065702
RL603 RELAY NRL-2P5A-DC12-192 1
25065702
RL605 RELAY NRL-2P5A-DC12-192 1 25065702
RL607 RELAY NRL-2P5A-DC12-192 1 25065702
RL691 RELAY NRL-1P10A-DC12-196 1 25065707
RL691 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
RL691 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
RL692 RELAY NRL-1P10A-DC12-196 1 25065707
RL692 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
RL692 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
[CHASSIS SCREW]
Q4170A HEAT-SINK HEAT-SINK(RAD-68) 1 27160211
Q4170B SCREW 3P+10FN(3BC) 1 82143010GR
Q4171A HEAT-SINK HEAT-SINK(RAD-68) 1 27160211
Q4171B SCREW 3P+10FN(3BC) 1 82143010GR
HT-R380

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
