JL501B WIRE TRAP NPLG-3P586 1 25055624
JL502B WIRE TRAP NPLG-5P588 1 25055626
JL901B WIRE TRAP NPLG-5P588 1 25055626
P101A SOCKET NSCT-11P2104 1 25052207
P131 PIN JACK NPJ-1PDO554 1 25045772
P2001A SOCKET IMSA-9142S-24A 1 25053234
P2002B SOCKET NSCT-15P2195 1 25052298
P2081 SOCKET NNA1-01-006 1 25053357
P5501A SOCKET NSCT-7P2187 1 25052290
P5502A SOCKET NSCT-15P2195 1 25052298
P5503A SOCKET NSCT-9P2189 1 25052292
P5504A SOCKET NSCT-7P2187 1 25052290
P701A SOCKET NSCT-31P2124 1 25052227
P751A SOCKET IMSA-9618S-09A 1 25053334R2
P8001A PLUG IMSA-9111B-16 1 25056620
P8002A PLUG IMSA-9111B-24 1 25056625
HT-R380
PC BOARD PARTS LIS
U004 DIS-AS(DISPLAY ASSY) BADIS-0373-1C * 1 1B247573-1C N <MDC>
U004 DIS-AS(DISPLAY ASSY) BADIS-0373-1D * 1 1B247573-1D N <MPB, MPP, MMO, MMQ>
U0040 DIS-AS(DISPLAY) BADIS-0373-1C 1 1B2475373-1C N <MDC>
U0040 DIS-AS(DISPLAY) BADIS-0373-1D 1 1B2475373-1D N <MPB, MPP, MMO, MMQ>
U0041 PWB(STANDBY_KEY/LED) BADIS-0374-1C 1 Included in "REF, NO, U004 N <MDC>
U0041 PWB(STANDBY_KEY/LED) BADIS-0374-1D 1 Included in "REF, NO, U004 N <MPB, MPP, MMO, MMQ>
U0042 PWB(VIDEO ASSY) BAVD-0375-1C 1 1B2475375-1C N <MDC>
U0042 PWB(VIDEO ASSY) BAVD-0375-1D 1 1B2475375-1D N <MPB, MPP, MMO, MMQ>
U0043 PWB(POW SUPPLY) BAETC-0376-1C 1 1B2475376-1C N <MDC>
U0043 PWB(POW SUPPLY) BAETC-0376-1D 1 1B2475376-1D N <MPB, MPP, MMO, MMQ>
U0044 PWB(HP-JACK) BAETC-0377-1C 1 1B2475377-1C N <MDC>
U0044 PWB(HP-JACK) BAETC-0377-1D 1 1B2475377-1D N <MPB, MPP, MMO, MMQ>
CIRCUIT. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
U7041 REMO SENS KSM-603TE5B 1 24130019
[SEMI CONDUCTOR]
D7002 ZENER D UDZS8.2B 1 224550820R2
D7033 ZENER D UDZS3.9B 1 224550390R2
D7151 LED SLI-343URC-TE7 1 225449T
D7152 LED SLI-343Y8C-TE7 1 225490T N
D9011 DIODE D5SBA20 1 22380130F
D9014 C-DIODE KDS4148U 1 223283R2
