Onkyo HT-R380 Service Manual

Q153 IC R1EX25064ASA00A 1 22242581R2
Q153 or IC M95640-WMN6TP ( 1) 22242643R2 N
Q181 TR KRC105S 1 2217290R2
Q181 or TR RN1405 ( 1) 2214500R2
Q2804 IC NJM4580M-D 1 22241448R2
Q301 IC PCM9210PTR 1 22242629R2 N
Q302 IC PCM1690DCAR 1 22242599R2
Q401 IC NJM4580M-D 1 22241448R2
Q402 IC NJM4580M-D 1 22241448R2
Q403 IC NJM4580M-D 1 22241448R2
Q405 IC NJM4580M-D 1 22241448R2
Q601 TR KRC104S 1 2216210R2
Q601 or TR RN1404 ( 1) 2214490R2
Q701 IC (MMPU) MPD70F3746GJ-GAE-AX(0345) 1 222W0079R303450
Q702 IC S-812C33AUA-C2N 1 22242222R2
Q703 IC S-812C56AUA-C3K 1 22242207R2
Q704 IC SN74CB3Q3305PWR 1 22242258R2
Q746 IC XC6221B332MR 1 22242633R2
Q751 TR KRC104S 1 2216210R2
Q751 or TR RN1404 ( 1) 2214490R2
Q752 TR KRA102S 1 2216220R2
Q752 or TR RN2402 ( 1) 2214530R2
Q753 TR KRA107S 1 2216350R2
Q753 or TR RN2407(TE85L_F) ( 1) 2216360R2
Q754 TR KRC102S 1 2216190R2
Q754 or TR RN1402 ( 1) 2214470R2
Q755 TR
KRA107S 1 2216350R2
Q755 or TR RN2407(TE85L_F) ( 1) 2216360R2
Q756 TR KRC102S 1 2216190R2
Q756 or TR RN1402 ( 1) 2214470R2
Q757 TR KRC107S 1 2216340R2
Q757 or TR RN1407 ( 1) 2216260R2
Q771 TR KRC104S 1 2216210R2
Q771 or TR RN1404 ( 1) 2214490R2
Q772 TR KRA102S 1 2216220R2
Q772 or TR RN2402 ( 1) 2214530R2
[TRANS COIL]
L101 CORE BLM18PG181SN1D 1 2350005R1 <MMO, MMQ, MPB, MPP>
L131 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L133 CHOKE COIL LBC2518T470M 1 231364M470R2
L134 CHOKE COIL LBC2518T470M 1 231364M470R2
L135 C-CARBON R RN72K1J-000JE 1 435030004R1

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
