Onkyo HT-R380 Service Manual

L153 CORE BLM18PG181SN1D 1 2350005R1
L2800 CORE BLM18PG181SN1D 1 2350005R1
L2801 CORE BLM18PG181SN1D 1 2350005R1
L2802 CORE BLM18PG181SN1D 1 2350005R1
L2803 EMIFIL BK1608LM182-T 1 230958R1
L2804 EMIFIL BK1608LM182-T 1 230958R1
L2805 EMIFIL BK1608LM182-T 1 230958R1
L2806 EMIFIL BK1608LM182-T 1 230958R1
L2807 EMIFIL BK1608LM182-T 1 230958R1
L2808 EMIFIL BK1608LM182-T 1 230958R1
L2809 EMIFIL BK1608LM182-T 1 230958R1
L2810 EMIFIL BK1608LM182-T 1 230958R1
L2811 EMIFIL BK1608LM182-T 1 230958R1
L2812 EMIFIL BK1608LM182-T 1 230958R1
L2813 EMIFIL BK1608LM182-T 1 230958R1
L2814 EMIFIL BK1608LM182-T 1 230958R1
L2815 EMIFIL BK1608LM182-T 1 230958R1
L2816 EMIFIL BK1608LM182-T 1 230958R1
L2817 EMIFIL BK1608LM182-T 1 230958R1
L2818 EMIFIL BK1608LM182-T 1 230958R1
L301 EMIFIL BK1608LM182-T 1 230958R1
L302 EMIFIL BK1608LM182-T 1 230958R1
L303 CHOKE COIL LBC2518T4R7M 1 231364M047R2
L304 CHOKE COIL LBC2518T4R7M 1 231364M047R2
L305 CHOKE COIL LBC2518T4R7M 1 231364M047R2
L307 C-CARBON R RN72K1J-000JE 1 435030004R1
L401 CHOKE COIL LBC2518T4R7M 1
231364M047R2
L402 CHOKE COIL LBC2518T4R7M 1 231364M047R2
L500 CORE BLM18PG181SN1D 1 2350005R1
L742 CHOKE COIL BLM21PG221SN1 1 230949R2
L743 CORE BLM18PG181SN1D 1 2350005R1
L744 CORE BLM18PG181SN1D 1 2350005R1
L746 CORE BLM18PG181SN1D 1 2350005R1
L747 CORE BLM18PG181SN1D 1 2350005R1
X101 CRYSTAL HC-49S 4.332MHz 1 3010469T <MMO, MMQ, MPB, MPP>
X171 CRYSTAL HC-49US24.576MHz 1 3010490T N
X171A CUSHION (BUTYL) 1 28141748
X501 CERA LOCK CSTCR5M00G53-B0 1 3010356R2
[CAPACITOR]
C102 C-CERA C CK725F1E-104Z1 1 NSP
C103 UTSP C CE04W50V-10M(UTSP) 1 397581007T <MMO, MMQ, MPB, MPP>
C104 UTSP C CE04W50V-10M(UTSP) 1 397581007T <MMO, MMQ, MPB, MPP>

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
