Onkyo HT-R380 Service Manual

C105 C-CERA C CK725F1E-104Z1 1 NSP <MMO, MMQ, MPB, MPP>
C106 C-CERA C CC725CH1H-331J1 1 NSP <MMO, MMQ, MPB, MPP>
C107 C-CERA C CK725F1E-104Z1 1 NSP <MMO, MMQ, MPB, MPP>
C108 C-CERA C CC725CH1H-150J1 1 NSP <MMO, MMQ, MPB, MPP>
C109 C-CERA C CC725CH1H-150J1 1 NSP <MMO, MMQ, MPB, MPP>
C110 C-CERA C CC725CH1H-331J1 1 NSP <MMO, MMQ, MPB, MPP>
C111 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C112 C-CERA C CK725F1E-104Z1 1 NSP
C113 C-CERA C CC725CH1H-221J1 1 NSP <MMO, MMQ, MPP>
C114 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C130 C-CERA C CK725F1E-104Z1 1 NSP
C131 C-CERA C CC725CH1H-101J1 1 NSP
C133 C-CERA C CK725B1C-104K1 1 NSP
C135 C-CERA C CC725CH1H-080D1 1 NSP
C139 UTSP C CE04W10V-220M(UTSP) 1 397532217T
C140 C-CERA C CK725F1E-104Z1 1 NSP
C141 C-CERA C CK725F1E-104Z1 1 NSP
C142 C-CERA C CK725F1E-104Z1 1 NSP
C143 C-CERA C CC725CH1H-330J1 1 NSP
C144 C-CERA C CC725CH1H-330J1 1 NSP
C145 UTSP C CE04W10V-220M(UTSP) 1 397532217T
C151 C-CERA C CK725F1E-104Z1 1 NSP
C172 C-CERA C CC725CH1H-180J1 1 NSP
C173 C-CERA C CC725CH1H-180J1 1 NSP
C2850 C-CERA C CC725CH1H-471J1 1 NSP
C2851 C-CERA C
CC725CH1H-471J1 1 NSP
C2852 C-CERA C CC725CH1H-470J1 1 NSP
C2855 C-CERA C CK725F1E-104Z1 1 NSP
C2870 C-CERA C CC725CH1H-101J1 1 NSP
C2871 C-CERA C CC725CH1H-101J1 1 NSP
C2877 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C2878 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C2880 C-CERA C CC725CH1H-101J1 1 NSP
C2881 C-CERA C CC725CH1H-101J1 1 NSP
C2882 C-CERA C CC725CH1H-101J1 1 NSP
C2883 C-CERA C CC725CH1H-101J1 1 NSP
C2884 C-CERA C CK732B1A-105K 1 NSP
C2885 C-CERA C CK732B1A-105K 1 NSP
C2886 C-CERA C CC725CH1H-471J1 1 NSP
C2887 C-CERA C CC725CH1H-471J1 1 NSP
C2888 C-CERA C CK725F1E-104Z1 1 NSP
C2889 C-CERA C CK725F1E-104Z1 1 NSP

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
