Onkyo HT-R380 Service Manual

C2891 C-CERA C CK732B1A-105K 1 NSP
C2892 C-CERA C CK732B1A-105K 1 NSP
C2893 C-CERA C CC725CH1H-471J1 1 NSP
C2894 C-CERA C CC725CH1H-471J1 1 NSP
C2895 C-CERA C CC725CH1H-471J1 1 NSP
C2896 C-CERA C CC725CH1H-471J1 1 NSP
C2897 C-CERA C CK732B1A-105K 1 NSP
C2898 C-CERA C CK732B1A-105K 1 NSP
C305 C-CERA C CK725F1E-104Z1 1 NSP
C306 UTSP C CE04W10V-470M(UTSP) 1 397534717T
C307 C-CERA C CK725F1E-104Z1 1 NSP
C312 C-CERA C CC725CH1H-221J1 1 NSP
C313 C-CERA C CK725F1E-104Z1 1 NSP
C314 UTSP C CE04W10V-470M(UTSP) 1 397534717T
C315 C-CERA C CK725B1H-472K1 1 NSP
C316 C-CERA C CK725B1H-473K1 1 NSP
C317 C-CERA C CK725F1E-104Z1 1 NSP
C318 UTSP C CE04W10V-470M(UTSP) 1 397534717T
C319 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C320 C-CERA C CK725B1H-223K1 1 NSP
C351 UTSP C CE04W10V-470M(UTSP) 1 397534717T
C352 C-CERA C CK725F1E-104Z1 1 NSP
C353 UTSP C CE04W10V-470M(UTSP) 1 397534717T
C354 C-CERA C CK725F1E-104Z1 1 NSP
C355 C-CERA C CK725F1E-104Z1 1 NSP
C356 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C357 C-CERA C CK725F1E-104Z1 1
NSP
C400 UPZ C 2AUPZTF471JE 1 376334714T
C401 UPZ C 2AUPZTF471JE 1 376334714T
C402 UPZ C 2AUPZTF471JE 1 376334714T
C403 UPZ C 2AUPZTF471JE 1 376334714T
C404 UPZ C 2AUPZTF471JE 1 376334714T
C407 UPZ C 2AUPZTF471JE 1 376334714T
C410 UPZ C 2AUPZTF101JE 1 376331014T
C411 UPZ C 2AUPZTF101JE 1 376331014T
C412 UPZ C 2AUPZTF101JE 1 376331014T
C413 C-CERA C CC725CH1H-101J1 1 NSP
C414 C-CERA C CC725CH1H-101J1 1 NSP
C417 UPZ C 2AUPZTF101JE 1 376331014T
C420 UPZ C 2AUPZTF101JE 1 376331014T
C421 UPZ C 2AUPZTF101JE 1 376331014T
C422 UPZ C 2AUPZTF101JE 1 376331014T

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
