Onkyo HT-R380 Service Manual

C423 C-CERA C CC725CH1H-101J1 1 NSP
C424 C-CERA C CC725CH1H-101J1 1 NSP
C427 UPZ C 2AUPZTF101JE 1 376331014T
C470 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C471 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C498 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C499 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C501 UTSP C CE04W50V-4.7M(UTSP) 1 397580477T
C502 C-CERA C CK725F1E-104Z1 1 NSP
C503 C-CERA C CK725F1E-104Z1 1 NSP
C504 C-CERA C CK725F1E-104Z1 1 NSP
C505 C-CERA C CK725F1E-104Z1 1 NSP
C507 C-CERA C CK725F1E-104Z1 1 NSP
C508 C-CERA C CK725F1E-104Z1 1 NSP
C509 C-CERA C CK725B0J-106K 1 NSP
C511 C-CERA C CK725B1H-102K1 1 NSP
C512 C-CERA C CK725B1H-102K1 1 NSP
C513 C-CERA C CC725CH1H-101J1 1 NSP
C514 C-CERA C CC725CH1H-101J1 1 NSP
C515 C-CERA C CC725CH1H-101J1 1 NSP
C516 C-CERA C CC725CH1H-101J1 1 NSP
C517 C-CERA C CK725F1E-104Z1 1 NSP
C518 C-CERA C CK725B1H-102K1 1 NSP
C519 C-CERA C CK725B1H-102K1 1 NSP
C520 C-CERA C CK725B1H-102K1 1 NSP
C521 C-CERA C CK725B1H-102K1 1 NSP
C522 C-CERA C CK725F1E-104Z1 1
NSP
C523 C-CERA C CK725B1H-102K1 1 NSP
C524 C-CERA C CK725B1H-102K1 1 NSP
C525 C-CERA C CK725F1E-104Z1 1 NSP
C526 C-CERA C CK725B1H-102K1 1 NSP
C527 C-CERA C CK725B1H-102K1 1 NSP
C528 C-CERA C CK725F1E-104Z1 1 NSP
C551 C-CERA C CK725F1E-104Z1 1 NSP
C552 C-CERA C CK725F1E-104Z1 1 NSP
C613 C-CERA C CK732B1C-474K 1 NSP
C629 C-CERA C CK725F1E-104Z1 1 NSP
C701 C-CERA C CK725F1E-104Z1 1 NSP
C705 C-CERA C CK725B0J-106K 1 NSP
C706 UTSP C CE04W16V-470M(UTSP) 1 397544717T
C707 UTSP C CE04W10V-100M(UTSP) 1 397531017T
C708 UTSP C CE04W10V-470M(UTSP) 1 397534717T

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
