Onkyo HT-R380 Service Manual

C709 C-CERA C CK725F1E-104Z1 1 NSP
C710 C-CERA C CK725F1E-104Z1 1 NSP
C744 C-CERA C CK725F1E-104Z1 1 NSP
C745 C-CERA C CK725B0J-106K 1 NSP
C748 UTSP C CE04W10V-100M(UTSP) 1 397531017T
C751 UTSP C CE04W50V-0.47M(UTSP) 1 397584797T
C753 UTSP C CE04W10V-470M(UTSP) 1 397534717T
C771 UTSP C CE04W50V-0.47M(UTSP) 1 397584797T
C772 C-CERA C CK732B1C-474K 1 NSP
C800 C-CERA C CK725F1E-104Z1 1 NSP
C801 C-CERA C CK725B1H-103K1 1 NSP
C802 C-CERA C CK725F1E-104Z1 1 NSP
[RESISTOR]
R107 C-CARBON R RN72K1J-101JE 1 NSP <MMO, MMQ, MPB, MPP>
R108 C-CARBON R RN72K1J-101JE 1 NSP <MMO, MMQ, MPB, MPP>
R110 C-CARBON R RN72K1J-103JE 1 NSP
R112 METAL O R RS1WBJ-22 1 443622204T
R113 C-CARBON R RN72K1J-221JE 1 NSP
R114 C-CARBON R RN72K1J-221JE 1 NSP
R115 C-CARBON R RN72K1J-333JE 1 NSP
R131 C-CARBON R RN72K1J-750JE 1 NSP
R133 C-CARBON R RN72K1J-100JE 1 NSP
R137 C-CARBON R RN72K1J-103JE 1 NSP
R139 C-CARBON R RN72K1J-823JE 1 NSP
R141 C-CARBON R RN72K1J-470JE 1 NSP
R142 C-CARBON R RN72K1J-470JE 1 NSP
R151 C-CARBON R RN72K1J-103JE 1 NSP
R152
C-CARBON R RN72K1J-103JE 1 NSP
R153 C-CARBON R RN72K1J-222JE 1 NSP
R154 C-CARBON R RN72K1J-103JE 1 NSP
R181 METAL R RNU1/2WCJ-4.7 1 453530474T
R182 METAL R RNU1/2WCJ-1 1 453530104T
R2800 THERMISTOR FUSB090F 1 4000252T
R2804 C-CARBON R RN72K1J-123JE 1 NSP
R2805 C-CARBON R RN72K1J-123JE 1 NSP
R2806 C-CARBON R RN72K1J-223JE 1 NSP
R2807 C-CARBON R RN72K1J-223JE 1 NSP
R2808 C-CARBON R RN72K1J-123JE 1 NSP
R2809 C-CARBON R RN72K1J-123JE 1 NSP
R2810 C-CARBON R RN72K1J-223JE 1 NSP
R2811 C-CARBON R RN72K1J-223JE 1 NSP
R2820 C-CARBON R RN72K1J-471JE 1 NSP

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
