Onkyo HT-R380 Service Manual

R4111 C-CARBON R RN72K1J-222JE 1 NSP
R4112 C-CARBON R RN72K1J-222JE 1 NSP
R4113 C-CARBON R RN72K1J-222JE 1 NSP
R4114 C-CARBON R RN72K1J-222JE 1 NSP
R4117 C-CARBON R RN72K1J-271JE 1 NSP
R4127 C-CARBON R RN72K1J-101JE 1 NSP
R4130 C-CARBON R RN72K1J-221JE 1 NSP
R4131 C-CARBON R RN72K1J-473JE 1 NSP
R4132 C-CARBON R RN72K1J-153JE 1 NSP
R4133 C-CARBON R RN72K1J-122JE 1 NSP
R4134 C-CARBON R RN72K1J-103JE 1 NSP
R4160 METAL R ( ! ) RNU1WCJ-0.22 1 453632294T
R4161 METAL R ( ! ) RNU1WCJ-0.22 1 453632294T
R4166 C CARBON R RN72K1J-220JE 1 NSP
R4167 C CARBON R RN72K1J-220JE 1 NSP
R4174 METAL O R RS1WBJ-68 1 443626804T
R4175 METAL O R RS1WBJ-68 1 443626804T
R4176 METAL O R RS1WBJ-15 1 443621504T
R4177 METAL O R RS1WBJ-15 1 443621504T
R4181 C-CARBON R RN72K1J-224JE 1 NSP
R4190 C-CARBON R RN72K1J-224JE 1 NSP
R4192 C-CARBON R RN72K1J-224JE 1 NSP
R4193 C-CARBON R RN72K1J-224JE 1 NSP
R4194 C-CARBON R RN72K1J-224JE 1 NSP
R4213 C-CARBON R RN72K1J-000JE 1 NSP
R4303 C-CARBON R RN72K1J-512JE 1 NSP
R4304 C-CARBON R RN72K1J-512JE 1
NSP
R6010 C-CARBON R RN72K1J-102JE 1 NSP
R6011 C-CARBON R RN72K1J-102JE 1 NSP
R6012 C-CARBON R RN72K1J-102JE 1 NSP
R6013 C-CARBON R RN72K1J-102JE 1 NSP
R6014 C-CARBON R RN72K1J-102JE 1 NSP
R6017 C-CARBON R RN72K1J-102JE 1 NSP
R6020 CARBON R R16J-56K 1 417345634T
R6021 CARBON R R16J-56K 1 417345634T
R6022 CARBON R R16J-56K 1 417345634T
R6023 CARBON R R16J-56K 1 417345634T
R6024 CARBON R R16J-56K 1 417345634T
R6027 CARBON R R16J-56K 1 417345634T
R6030 CARBON R R16J-2.2K 1 417342224T
R6031 CARBON R R16J-2.2K 1 417342224T
R6032 CARBON R R16J-2.2K 1 417342224T

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
