Onkyo HT-R380 Service Manual

TX-SR308 / 508 HT-R280/ 380/ 578/C230
TROUBLE SHOOT-4
No Pictuer
TX-SR308 / 508 HT-R280/ 380/ 578/C230
NN
YNY Y
Note:
This is just for general reference and does not include every single case.
No Picture from Analog
inputs
䋨COMPONENT/S_VIDEO䋩
BAVD-0375䋨Video)
JL952_1pin-3pinn: AC10V
Replace Power
transformer or
Repair its peripheral
circuit.
BAVD-0375䋨Video)
Replace Video Board or
Replace Q2001 and repair
its peripheral circuit.
No Picture from
HDMI input
BADG-0401䋨HDMI Board)
JL801
2pin / 4pin: 䋫12V
BADG-0401䋨HDMI Board)
Replace HDMI Board or
Repair Q2001 and its
peripheral circuit.
BAVD-0375䋨Video)
JL952_1pin-3pin: AC10V
BAVD-0375䋨Video)
Replace Video Board or
Repair
D9011/R9013/R9012 and
their peripheral circuit.

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
