Onkyo HT-R380 Service Manual

R477 C-CARBON R RN72K1J-182JE 1 NSP
R480 C-CARBON R RN72K1J-273JE 1 NSP
R481 C-CARBON R RN72K1J-273JE 1 NSP
R482 C-CARBON R RN72K1J-223JE 1 NSP
R483 C-CARBON R RN72K1J-223JE 1 NSP
R484 C-CARBON R RN72K1J-103JE 1 NSP
R485 C-CARBON R RN72K1J-103JE 1 NSP
R486 C-CARBON R RN72K1J-103JE 1 NSP
R487 C-CARBON R RN72K1J-103JE 1 NSP
R490 C-CARBON R RN72K1J-102JE 1 NSP
R491 C-CARBON R RN72K1J-102JE 1 NSP
R498 C-CARBON R RN72K1J-100JE 1 NSP
R499 C-CARBON R RN72K1J-100JE 1 NSP
R501 C-CARBON R RN72K1J-473JE 1 NSP
R503 C-CARBON R RN72K1J-103JE 1 NSP
R504 C-CARBON R RN72K1J-000JE 1 NSP
R505 C-CARBON R RN72K1J-103JE 1 NSP
R506 C-CARBON R RN72K1J-221JE 1 NSP
R508 C-CARBON R RN72K1J-105JE 1 NSP
R509 C-CARBON R RN72K1J-221JE 1 NSP
R510 C-CARBON R RN72K1J-470JE 1 NSP
R511 C-CARBON R RN72K1J-473JE 1 NSP
R512 C-CARBON R RN72K1J-221JE 1 NSP
R514 C-CARBON R RN72K1J-470JE 1 NSP
R515 C-CARBON R RN72K1J-470JE 1 NSP
R516 C-CARBON R RN72K1J-470JE 1 NSP
R517 C-CARBON R RN72K1J-470JE 1
NSP
R518 C-CARBON R RN72K1J-103JE 1 NSP
R519 C-CARBON R RN72K1J-470JE 1 NSP
R520 C-CARBON R RN72K1J-103JE 1 NSP
R521 C-CARBON R RN72K1J-470JE 1 NSP
R522 C-CARBON R RN72K1J-470JE 1 NSP
R523 C-CARBON R RN72K1J-470JE 1 NSP
R527 C-CARBON R RN72K1J-470JE 1 NSP
R529 C-CARBON R RN72K1J-470JE 1 NSP
R530 C-CARBON R RN72K1J-470JE 1 NSP
R531 C-CARBON R RN72K1J-103JE 1 NSP
R532 C-CARBON R RN72K1J-472JE 1 NSP
R533 C-CARBON R RN72K1J-472JE 1 NSP
R534 C-CARBON R RN72K1J-223JE 1 NSP
R535 C-CARBON R RN72K1J-223JE 1 NSP
R536 C-CARBON R RN72K1J-223JE 1 NSP

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
