Onkyo HT-R380 Service Manual

R537 C-CARBON R RN72K1J-223JE 1 NSP
R538 C-CARBON R RN72K1J-103JE 1 NSP
R539 C-CARBON R RN72K1J-470JE 1 NSP
R540 C-CARBON R RN72K1J-470JE 1 NSP
R541 C-CARBON R RN72K1J-470JE 1 NSP
R542 C-CARBON R RN72K1J-470JE 1 NSP
R543 C-CARBON R RN72K1J-103JE 1 NSP
R544 C-CARBON R RN72K1J-221JE 1 NSP
R545 C-CARBON R RN72K1J-221JE 1 NSP
R546 C-CARBON R RN72K1J-221JE 1 NSP
R547 C-CARBON R RN72K1J-221JE 1 NSP
R548 C-CARBON R RN72K1J-221JE 1 NSP
R550 C-CARBON R RN72K1J-470JE 1 NSP
R551 C-CARBON R RN72K1J-103JE 1 NSP
R552 C-CARBON R RN72K1J-103JE 1 NSP
R553 C-CARBON R RN72K1J-470JE 1 NSP
R554 C-CARBON R RN72K1J-103JE 1 NSP
R556 C-CARBON R RN72K1J-470JE 1 NSP
R557 C-CARBON R RN72K1J-103JE 1 NSP
R558 C-CARBON R RN72K1J-470JE 1 NSP
R559 C-CARBON R RN72K1J-272JE 1 NSP
R562 C-CARBON R RN72K1J-103JE 1 NSP
R563 C-CARBON R RN72K1J-103JE 1 NSP
R565 C-CARBON R RN72K1J-470JE 1 NSP
R566 C-CARBON R RN72K1J-222JE 1 NSP
R567 C-CARBON R RN72K1J-470JE 1 NSP
R568 C-CARBON R RN72K1J-222JE 1
NSP
R569 C-CARBON R RN72K1J-102JE 1 NSP
R570 C-CARBON R RN72K1J-273JE 1 NSP
R571 C-CARBON R RN72K1J-102JE 1 NSP
R572 C-CARBON R RN72K1J-273JE 1 NSP
R573 C-CARBON R RN72K1J-221JE 1 NSP
R574 C-CARBON R RN72K1J-470JE 1 NSP
R575 C-CARBON R RN72K1J-470JE 1 NSP
R576 C-CARBON R RN72K1J-470JE 1 NSP
R578 C-CARBON R RN72K1J-470JE 1 NSP
R579 C-CARBON R RN72K1J-470JE 1 NSP
R580 C-CARBON R RN72K1J-103JE 1 NSP
R581 C-CARBON R RN72K1J-103JE 1 NSP
R582 C-CARBON R RN72K1J-221JE 1 NSP
R583 C-CARBON R RN72K1J-221JE 1 NSP
R584 C-CARBON R RN72K1J-103JE 1 NSP

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
