Onkyo HT-R380 Service Manual

R585 C-CARBON R RN72K1J-221JE 1 NSP
R586 C-CARBON R RN72K1J-103JE 1 NSP
R587 C-CARBON R RN72K1J-221JE 1 NSP
R588 C-CARBON R RN72K1J-103JE 1 NSP
R589 C-CARBON R RN72K1J-470JE 1 NSP
R590 C-CARBON R RN72K1J-103JE 1 NSP
R591 C-CARBON R RN72K1J-470JE 1 NSP
R592 C-CARBON R RN72K1J-470JE 1 NSP
R593 C-CARBON R RN72K1J-221JE 1 NSP
R594 C-CARBON R RN72K1J-221JE 1 NSP
R595 C-CARBON R RN72K1J-221JE 1 NSP
R596 C-CARBON R RN72K1J-103JE 1 NSP
R597 C-CARBON R RN72K1J-470JE 1 NSP
R598 C-CARBON R RN72K1J-221JE 1 NSP
R599 C-CARBON R RN72K1J-103JE 1 NSP
R600 C-CARBON R RN72K1J-103JE 1 NSP
R601 C-CARBON R RN72K1J-470JE 1 NSP
R602 C-CARBON R RN72K1J-470JE 1 NSP
R603 C-CARBON R RN72K1J-470JE 1 NSP
R604 C-CARBON R RN72K1J-103JE 1 NSP
R605 C-CARBON R RN72K1J-221JE 1 NSP
R606 C-CARBON R RN72K1J-470JE 1 NSP
R607 C-CARBON R RN72K1J-470JE 1 NSP
R608 C-CARBON R RN72K1J-470JE 1 NSP
R609 C-CARBON R RN72K1J-102JE 1 NSP
R611 C-CARBON R RN72K1J-102JE 1 NSP
R613 C-CARBON R RN72K1J-102JE 1
NSP
R614 C-CARBON R RN72K1J-103JE 1 NSP
R615 C-CARBON R RN72K1J-101JE 1 NSP
R616 C-CARBON R RN72K1J-103JE 1 NSP
R617 C-CARBON R RN72K1J-221JE 1 NSP
R618 C-CARBON R RN72K1J-103JE 1 NSP
R619 C-CARBON R RN72K1J-470JE 1 NSP
R620 C-CARBON R RN72K1J-103JE 1 NSP
R621 C-CARBON R RN72K1J-221JE 1 NSP
R622 C-CARBON R RN72K1J-470JE 1 NSP
R623 C-CARBON R RN72K1J-103JE 1 NSP
R625 C-CARBON R RN72K1J-470JE 1 NSP
R626 C-CARBON R RN72K1J-103JE 1 NSP
R627 C-CARBON R RN72K1J-000JE 1 NSP
R628 C-CARBON R RN72K1J-221JE 1 NSP
R629 C-CARBON R RN72K1J-221JE 1 NSP

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
